Sumitomo Diamond Turning Insert, Diamond, 3, DCGT, 1, Cermet DCGT32.51R-T1500A - main

Diamond Turning Insert, Diamond, 3, DCGT, 1, Cermet

  • Mfr # DCGT32.51R-T1500A

  • Zoro # G6324915

product price: $11.35
/ea
Sold in multiples of 10 for $113.50

Key Features

Insert Shape
Diamond
Insert Style
DCGT
Inscribed Circle
3
Insert Size
32.51
Chip-Breaker
Yes
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
DCGT32.51R-T1500A
Zoro #
G6324915
UPC #
-
Country of Origin
Japan

Dimensions

Insert Size
32.51
Corner Radius
1
Insert Thickness
0.1560"
Nose Radius
0.0156"
Mounting Hole Dia.
0.173"
Thickness
2.5

Details

Item
Diamond Turning Insert
Insert Shape
Diamond
Insert Style
DCGT
Inscribed Circle
3
Chip-Breaker
Yes
Grade
T1500A
Insert Material
Cermet
Insert Application
Finishing
Rake
10 Degrees
ISO Number
DCGT11T304R-W
Stainless (M) Compatibility
Yes
Cast Iron (K) Compatibility
No
For Use With
Toolholders, Boring Bars
Steel (P) Compatibility
Yes
Super Alloy (S) Compatibility
No
Coating
Cermet
Non Ferrous (N) Compatibility
No
Hardened (H) Compatibility
No
Cutting Direction
Neutral
ANSI Number
DCGT32.51R-T1500A
Mounting Style
Screw-On
No. of Edges
2
Workpiece Compatibility
Stainless (M), Steel (P)
Included Angle
55 Degrees
Primary Material Application ISO Code
P05 - P30
Number of Cutting Edges
2
Shape
Rhombic
Primary Material Application
Steel
Chip-Breaker Style
Single
Clearance Angle
7 Degrees
Material - Machining
Cermet
Insert Holding Type
Countersink Hole
Measurement System
Fractional Inch
Features
Excellent Wear Resistance and Fracture Resistance
Cutting Application
Turning
Manufacturer Grade
T1500A
ANSI Code
DCGT32.51R
Material
Cermet
Application
Finishing
Style
DCGT

Description

Diamond Turning Insert, Inscribed Circle 3/8 in, ANSI Code DCGT32.51R, Chip-Breaker Style Single, Clearance Angle 7 Degrees
