  11. 25 MODII HDR SRST B/A .100CL
Te Connectivity 25 MODII HDR SRST B/A .100CL 7-146274-5 - main

25 MODII HDR SRST B/A .100CL

  • Mfr # 7-146274-5

  • Zoro # G000939895

product price: $4.39
/ea
Sold in multiples of 17 for $74.63

Key Features

Type
Breakaway
Color
Black
Insulation Material
Liquid Crystal Polymer
Max. Voltage
30V AC
Maximum Voltage
30 V AC
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
7-146274-5
Zoro #
G000939895
UPC #
-
Country of Origin
Mexico

Dimensions

Contact Plating Thickness
100 to 200 µin

Details

Item
PCB Mount Header
Type
Breakaway
Color
Black
Insulation Material
Liquid Crystal Polymer
Max. Voltage
30V AC
Maximum Voltage
30 V AC
Current
3 A
Standards
CSA LR7189; UL E28476
Maximum Operating Temperature
105 Degrees C
UL 94 Flammability Rating
V-0
Terminal Type
Through Hole
Material
Liquid Crystal Polymer
Features
With Board Standoff
Hole Center to Center
2.54 mm
Connection Material
Phosphor Bronze
Max. Temp.
105°C
Current Rating
3 A
Contact Finish
Tin Plated
Number of Contacts
25
Number of Rows
1
Contact Type
Pin
Flammability Rating
UL 94 V-0
Terminal Finish
Tin Plated
Connector Terminates To
Printed Circuit Board

Description
