Spring Collet, ER50, 20mm
Mfr # 04250-20
Zoro # G0512228
product price:Â
$
70.89
/ea
Key Features
Collet Series
ER50
Range
20.0mm to 19.6mm
Coolant Through
Yes
For Use With
BR Collet Chuck Series, DR Collet Chuck Series, ER Collet Chuck Series, ESX Collet Chuck Series, RD Collet Chuck Series
Coolant Fed
Coolant Through
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- 04250-20
- Zoro #
- G0512228
- UPC #
- -
- Country of Origin
- Taiwan, Province of China
- Item
- Collet
- Collet Series
- ER50
- Range
- 20.0mm to 19.6mm
- Coolant Through
- Yes
- For Use With
- BR Collet Chuck Series, DR Collet Chuck Series, ER Collet Chuck Series, ESX Collet Chuck Series, RD Collet Chuck Series
- Coolant Fed
- Coolant Through
- Number of Slots
- 8
- Compatible with Product Type
- AR, BR Series, DR, ESX, RD
- Collet Type
- Standard
- Measurement System
- Metric
- TIR Max.
- 0.0002 in
- Face Shape
- Round
- Material
- High-Carbon Steel
- Collapse Range - Minimum
- 18 mm
- Compatible Collet Chuck
- AR, BR, DR, ESX, RD
- Collapse Range - Maximum
- 20 mm
- Operating Pressure - Maximum
- 2,000 psi
- T.I.R. Tolerance
- 0.0002 in
- Taper Angle
- 8 Degrees
- Bore Shape
- Round
- Finish
- Precision Ground
- Torque - Maximum
- 130 ft-lb
Description
Collet, ER50, Round, Overall Length 60 mm
