Cordset, 6.56 ft., Gray, 250VAC/300VDC

  • Mfr # XZCPV1141L2
  • Zoro # G6104357
product price:
$
15.69
/ea

Key Features

Product Type
Single Ended
End 1 Number of Pins
4
Wire Size
18 AWG
Cable Length
6.56 ft
Cable Jacket Material
PVC
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
XZCPV1141L2
Zoro #
G6104357
UPC #
785901457268
Country of Origin
Czechia
Item
Cordset
Product Type
Single Ended
End 1 Number of Pins
4
Cable Jacket Material
PVC
Cable Jacket Color
Gray
IP Rating
IP65, IP67
Max. Amps
3 A
Maximum Operating Temperature
176 Degrees F
End 1 Connection Type
M12
Max. Voltage
250 V AC, 300 V DC
Temp. Range
-25 Degrees to 80 Degrees C
Features
Good Resistance to Moderate Mechanical Stress, Chemical Products and Humid Environments, Easy Cable Stripping
Standards
CSA Certified, IEC, UL Listed
End 1 Gender and Plug End
Female Straight
End 1 Keyway
Single
End 2 Connection Type
Bare Wire
Number of Conductors
4
End 1 Thread
M12
End 2 Gender and Plug End
Bare Wire
End 1 Number of Keyways
1
End 1 Mounting Orientation
Straight
End 1 Gender
Female
Minimum Operating Temperature
-13 Degrees F
Number of Wires
4
Cable Composition
4 x 0.25 mm²
Electrical Connection
straight female connector M12, 4 pins
Line Rated Current
3A
Minimum Insulating Resistance
1 GΩ
Contact Resistance
5000µOhm
Ambient Air Temperature For Operation
-25-80°C static
Ambient Air Temperature For Storage
-25-80°C
Series Name
general purpose
Product Certifications
cULus
Accessory / Separate Part Category
cabling accessory
Status Led
without
Collar Material
metal
Accessory / Separate Part Type
pre-wired connectors
Cable Connector Fixing
screw-on
[Ue] Rated Operational Voltage
250 V AC || 300 V DC

Dimensions

Wire Size
18 AWG
Cable Length
6.56 ft
Cable Outer Diameter
4.6 mm
Fits Chest Size
Good Resistance to Moderate Mechanical Stress, Chemical Products and Humid Environments, Easy Cable Stripping

Description

Cordset, End 1 Gender Female, End 1 Thread M12, End 1 Number of Pins 4, End 1 Mounting Orientation Straight, End 1 Connection Type M12, End 2 Gender Not Applicable, End 2 Thread Not Applicable, End 2 Connection Type Bare Wire, Cable Length 2 m, Cable Jacket Color Gray, Cable Jacket Material PVC, Max. Amps 3 A, Wire Size 18 AWG, Maximum Operating Temperature 176 Degrees F, Minimum Operating Temperature -13 Degrees F, IP Rating IP65, IP67, Standards CSA Certified, IEC, UL Listed
