Telemecanique Sensors Heavy Duty Limit Switch, Plunger, Roller, 2NC/2NO, 10A at 600V AC, Actuator Location: Top 9007C62D - main
Shop TELEMECANIQUE SENSORS

Heavy Duty Limit Switch, Plunger, Roller, 2NC/2NO, 10A at 600V AC, Actuator Location: Top

  • Mfr # 9007C62D

  • Zoro # G0296107

product price:  $271.99
/ea
Free Shipping & Returns

Key Features

Basic Actuator Style - Limit Switch
Plunger
Actuator Style - Limit Switch
Plunger, Roller
Contact Form- Switches
2NC/2NO
Actuator Location - Limit Switch
Top
AC Contact Rating - Limit Switch
10A at 600V
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
9007C62D
Zoro #
G0296107
UPC #
785901500667
Country of Origin
Mexico

Dimensions

Width
1.55"
Actuator Length - Limit Switch
0.95 in
Body Height - Limit Switch
2.5 in
Roller Dia.
0.63 in
Actuator Length
0.95"
Depth
1.79"
Roller Width
0.12 in
Height
4.02"
Body Width - Limit Switch
0.83 in
Body Depth - Limit Switch
1.14 in
Body Height
2.5 in
Body Depth
1.14 in
Body Width
0.83 in
Overall Height
4.98 in
Overall Depth
1.79 in
Mounting Hole Diameter
0.2 in
Overall Width
1.55 in
Manufacturer Warranty Length
18 mo
Roller Diameter
0.63 in

Details

Item
Heavy Duty Limit Switch
Basic Actuator Style - Limit Switch
Plunger
Actuator Style - Limit Switch
Plunger, Roller
Contact Form- Switches
2NC/2NO
Actuator Location - Limit Switch
Top
AC Contact Rating - Limit Switch
10A at 600V
DC Contact Rating - Limit Switch
10A at 600V
Body Style - Limit Switch
Miniature
Mounting - Limit Switch
Surface
Actuator Location (Limit Switch)
Top
Actuator Style
Roller Plunger
Mounting Hole Pattern - Limit Switch
2 Hole Diagonal
DC Contact Rating
10 A @ 600 V
Standards
C22-2-14-95, CE, CSA, EN 60947-1, EN 60947-5-1, IEC 60947, NEMA 250, UL Listed, UL 508
Wiring Entry
1/2 in NPT
Boot Sealed Actuator - Limit Switch
No
Amps
10
Actuator Location
Top
Operating Temp. Range
0 Degrees to 185 Degrees F
Limit Switch Style
Heavy Duty Limit Switch
Stem Thread - Limit Switch
No Stem
Basic Actuator Style (Limit Switch)
Plunger
Body Material
Zinc
Boot Sealed Actuator (Limit Switch)
No
Roller Material
Steel
IP Rating
IP67
AC Contact Rating
10 A @ 600 V
Contact Form - Limit Switch
2NC/2NO
Operating Force
4.0 in-lb
Actuator Style (Limit Switch)
Plunger, Roller
Movement
Horizontal
Mounting Hole Spacing - Limit Switch
2.35 in x 1.17 in
Contact Form
2NO/2NC
Voltage Rating
600VAC/DC
NEMA Rating
1, 12, 13, 2, 4, 6, 6P
Mounting Hole - Limit Switch
(2) 0.20 in dia
Travel
0.25 in
Series
9007C
Body Style (Limit Switch)
Miniature
Electrical Connection
Screw Clamp Terminals
Head Material
zinc
Special Features
lateral approach, 2 directions
Contact Material
silver contacts
Mechanical Durability
10000000 cycles
Electrical Durability
1000000 cycles
Shock Resistance
60 gn 9 ms IEC 60068-2-27
Short Circuit Protection
10 A CC non-time delay
Contact Action
snap action
Vibration Resistance
25 gn 10-150 Hz)IEC 60068-2-6
Weight
1.25 lb(US)
Actuation Type
by 30° cam
Head Type
plunger head
Operating Temperature - Minimum
-20 Degrees F
Operating Torque - Maximum
4 in-lb
Pretravel
0.08 in
Resistance Properties
Shock Resistant, Vibration Resistant
Mounting Style
Surface
Mounting Hole Horizontal Center to Center Distance
30 mm
Number of Mounting Holes
2
NEMA Enclosure Rating
1, 12, 13, 2, 4, 6, 6P
Operating Temperature - Maximum
185 Degrees F
Mounting Hole Vertical Center to Center Distance
60 mm
Body Configuration
Plug-In
Directional Movement
Linear
Boot Sealed Actuator
No Boot Included
Type Of Operator
steel spring return roller plunger
Number Of Poles
2

Description

Plug-In Limit Switch, Actuator Style - Limit Switch Plunger, Roller, Actuator Location - Limit Switch Top, AC Contact Rating - Limit Switch 10A @ 600V, DC Contact Rating - Limit Switch 10A @ 600V, Contact Form- Switches 2NC/2NO, Actuator Length - Limit Switch 0.95 in, Body Height - Limit Switch 2.5 in, Body Width - Limit Switch 0.83 in, Body Depth - Limit Switch 1.14 in, Boot Sealed Actuator - Limit Switch No, Body Style - Limit Switch Miniature, NEMA Rating 1, 12, 13, 2, 4, 6, 6P
