Telemecanique Sensors Inductive Proximity Sensor, PBT, 2 Wires XS7C4A1MPP20 - main

Inductive Proximity Sensor, PBT, 2 Wires

  • Mfr # XS7C4A1MPP20

  • Zoro # G3975042

product price: $206.99
/ea
Free Shipping & Returns

Key Features

Measurement Range
0 to 12 mm
Proximity Sensing Method
Inductive
Proximity Sensor Power Requirement
24 to 240V AC/DC
Length
40 mm
Width
117 mm
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
XS7C4A1MPP20
Zoro #
G3975042
UPC #
-
Country of Origin
France

Dimensions

Length
40 mm
Width
117 mm
Depth
40 mm

Details

Item
Proximity Sensor
Measurement Range
0 to 12 mm
Proximity Sensing Method
Inductive
Proximity Sensor Power Requirement
24 to 240V AC/DC
Proximity Sensor Electrical Connection
Screw-Clamp Terminals, 4 x 1.5 mm
Proximity Sensor Operating Frequency
Less than Or Equal to 25 Hz AC; Less than Or Equal to 50 Hz DC
Operating Temp. Range
-25 to 70 Degrees C
Description/Special Features
5 Positions Turret Head Detection Face; Supply ON 1 LED Green; Output State 1 LED Yellow
Standards
CCC; CSA; UL; CE Marked
IP Rating
IP65, IP67, IP69K
Application
general purpose
Maximum Delay Recovery
1.8 ms
Differential Travel
3...15% of Sr
Shock Resistance
50 gn 11 msEN 60068-2-27
Maximum Voltage Drop
<5.5 V closed)
Series
XS7
Switching Capacity
5...200 mA DC || 5...300 mA AC
Maximum Delay First Up
7.5 ms
Maximum Delay Response
1.2 ms
Vibration Resistance
25 gn +/- 2 mm 10-55 Hz)IEC 60068-2-6
Supply Voltage Limits
20-264 V AC/DC
Body Type
fixed
Storage Temp. Range
-40-85 °C
Body Material
PBT
Sensing Distance - Maximum
15 mm
Output Circuit Contact Form
NC/NO
Output Circuit Number of Wires
2
Output Circuit Type
AC/DC-Type
Style
Inductive

Description

Inductive sensor XS7 40x40x117 - PBT - S
