  8. Limit Switch, No Lever, Rotary, 1C/O, 10A at 240V AC, Actuator Location: Side
Telemecanique Sensors Limit Switch, No Lever, Rotary, 1C/O, 10A at 240V AC, Actuator Location: Side XCKJ20541 - main

Limit Switch, No Lever, Rotary, 1C/O, 10A at 240V AC, Actuator Location: Side

  • Mfr # XCKJ20541

  • Zoro # G0560178

product price:  $186.99
/ea
Free Shipping & Returns

Key Features

Basic Actuator Style - Limit Switch
Rotary
Actuator Style - Limit Switch
No Lever, Rotary
Contact Form- Switches
1C/O
Actuator Location - Limit Switch
Side
AC Contact Rating - Limit Switch
10A @ 240V
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
XCKJ20541
Zoro #
G0560178
UPC #
785901192268
Country of Origin
France

Dimensions

Body Height - Limit Switch
77 mm
Body Depth - Limit Switch
44 mm
Width
40 mm

Details

Item
Limit Switch
Basic Actuator Style - Limit Switch
Rotary
Actuator Style - Limit Switch
No Lever, Rotary
Contact Form- Switches
1C/O
Actuator Location - Limit Switch
Side
AC Contact Rating - Limit Switch
10A @ 240V
Amps
10
Body Material
zamak
IP Rating
IP66 conforming to IEC 60529
Certification
UL, CCC, CSA
Movement
rotary
Operating Temp. Range
-25-70 Degrees C
Standards
CENELEC EN 50041, EN 60947-5-1, CSA C22.2 No 14, IEC 60947-5-1, IEC 60204-1, UL 508, EN 60204-1
Body Style (Limit Switch)
fixed
Head Material
zamak
Series
XCKJ
Special Features
lateral approach, 1 or 2 programmable direction
Electrical Connection
screw-clamp terminals 1 x 0.75, 2 x 1.5 sq mm
Short Circuit Protection
10 A cartridge fuse gG
Mechanical Durability
30000000 cycles
Contact Action
snap action
Head Type
rotary head
Shock Resistance
50 gn 11 ms IEC 60068-2-27
Vibration Resistance
25 gn 10-500 Hz)IEC 60068-2-6
Electrical Durability
5000000 cycles, DC-13, inductive, 120 V, 4 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C, 5000000 cycles, DC-13, inductive, 24 V, 10 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C, 5000000 cycles, DC-13, inductive, 48 V, 7 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C
Operating Torque - Maximum
2.21 in-lb
Includes Actuator
No Actuator Included
Number Of Poles
2
Type Of Operator
spring return without operating lever

Description

Limit Switch
