  8. Limit Switch, No Lever, Rotary, SPDT, 10A at 300V AC, Actuator Location: Side
Telemecanique Sensors Limit Switch, No Lever, Rotary, SPDT, 10A at 300V AC, Actuator Location: Side 9007MS04S0400 - main

Limit Switch, No Lever, Rotary, SPDT, 10A at 300V AC, Actuator Location: Side

  • Mfr # 9007MS04S0400

  • Zoro # G0418336

product price:  $169.99
/ea
Free Shipping & Returns

Key Features

Basic Actuator Style - Limit Switch
Rotary
Actuator Style - Limit Switch
No Lever, Rotary
Contact Form- Switches
SPDT
Actuator Location - Limit Switch
Side
AC Contact Rating - Limit Switch
10A at 300V
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
9007MS04S0400
Zoro #
G0418336
UPC #
785901319610
Country of Origin
Mexico

Dimensions

Height
2.50"
Depth
1.39"
Body Height - Limit Switch
1.75 in
Body Depth - Limit Switch
0.62 in
Width
1.56"
Body Width - Limit Switch
1.58 in
Body Width
1.58 in
Body Depth
0.62 in
Overall Height
2.49 in
Manufacturer Warranty Length
18 mo
Mounting Hole Diameter
0.2 in
Body Height
1.75 in
Overall Width
1.56 in
Overall Depth
0.62 in

Details

Item
Limit Switch
Basic Actuator Style - Limit Switch
Rotary
Actuator Style - Limit Switch
No Lever, Rotary
Contact Form- Switches
SPDT
Actuator Location - Limit Switch
Side
AC Contact Rating - Limit Switch
10A at 300V
DC Contact Rating - Limit Switch
5A at 28V
Body Style - Limit Switch
Miniature
Mounting - Limit Switch
Surface
Boot Sealed Actuator - Limit Switch
No
Contact Form
1NO/1NC
Wiring Entry
Potted Cable
Travel
70 Degrees
Body Material
Zinc
Mounting Hole Spacing - Limit Switch
0.98 in
Movement
CCW, CW
Actuator Style
Rotary Head, No Lever
Contact Form - Limit Switch
SPDT
IP Rating
IP67
Body Style (Limit Switch)
Miniature
Number of Poles
1
Mounting Hole Pattern - Limit Switch
2 Hole Horizontal
Boot Sealed Actuator (Limit Switch)
No
NEMA Rating
1, 12, 13, 2, 4, 6, 6P
Operating Force
3.0 in-lb
Standards
CCC, CSA, CSA C22.2 No.14, EN/IEC 60204-1, EN/IEC 60947-5-1, UL 508, UL Listed
Amps
10 AC/5 DC
Actuator Style (Limit Switch)
Rotary, No Lever
DC Contact Rating
5 A @ 28 V
Limit Switch Style
General Purpose Limit Switch
Basic Actuator Style (Limit Switch)
Rotary
Stem Thread - Limit Switch
No Stem
Mounting Hole - Limit Switch
(2) 0.20 in dia
Actuator Location
Side
Electrical Connection
Pre-Wired Cable
AC Contact Rating
10 A @ 300 V
Operating Temp. Range
-4 Degrees to 221 Degrees F (-20 Degrees to 105 Degrees C)
Actuator Location (Limit Switch)
Side
Voltage Rating
240VAC/28VDC
Series
9007MS
Contact Material
silver contacts
Special Features
lateral approach, 2 directions
Certification
UL || CSA || CE
Vibration Resistance
10 gn 75-1200 Hz)IEC 60068-2-6
Shock Resistance
35 gn 9 ms IEC 60068-2-27
Electrical Durability
100000 cycles
Mechanical Durability
10000000 cycles
Actuation Type
CW and CCW || from left and right
Contact Action
snap action
Weight
1.2 lb(US)
Head Type
rotary head
Min. Actuation Velocity Horizontal
130 ft/min with 30° cam angle, levers only || 90 ft/min with 45° cam angle, levers only
Operating Temperature - Maximum
220 Degrees F
Mounting Style
Surface
Directional Movement
CCW/CW
Total Travel
70 Degrees
Resistance Properties
Shock Resistant, Vibration Resistant
NEMA Enclosure Rating
1, 12, 13, 2, 4, 6, 6P
Boot Sealed Actuator
No Boot Included
Number of Mounting Holes
2
Includes Actuator
No Actuator Included
Operating Torque - Maximum
3 in-lb
Operating Temperature - Minimum
-40 Degrees F
Mounting Hole Horizontal Center to Center Distance
25 mm
Type Of Operator
spring return without operating lever

Description

Limit Switch, Actuator Style - Limit Switch No Lever, Rotary, Actuator Location - Limit Switch Side, AC Contact Rating - Limit Switch 10A @ 300V, DC Contact Rating - Limit Switch 5A @ 28V, Contact Form- Switches SPDT, Body Height - Limit Switch 1.75 in, Body Width - Limit Switch 1.58 in, Body Depth - Limit Switch 0.62 in, Boot Sealed Actuator - Limit Switch No, Body Style - Limit Switch Miniature, NEMA Rating 1, 12, 13, 2, 4, 6, 6P, Mounting - Limit Switch Surface
