Shop SCHNEIDER ELECTRIC

Socket, General Purpose Relay, Square, 10 A, 11 Pins, Quick Connect

  • Mfr # 8501KUR13P14V20

  • Zoro # G1757436

product price:  $39.69
/ea

Key Features

Mounting Style
Socket
Electrical Connection
Quick-Connect
Base Shape
Square
Number of Pins
11
Coil Voltage
120V AC
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
8501KUR13P14V20
Zoro #
G1757436
UPC #
785901981756
Country of Origin
China

Dimensions

Overall Height - Relay
2.25 in
Flat Pin Width
0.189 in
Overall Depth
2.25 in
Body Width
1.37 in
Body Depth
1.4 in
Body Height
2.25 in

Details

Item
General Purpose Relay
Mounting Style
Socket
Electrical Connection
Quick-Connect
Base Shape
Square
Number of Pins
11
Coil Voltage
120V AC
Current Rating
10 A
Contact Form
3PDT
Contact Rating (AC)
12 A @ 240V
Contact Rating (DC)
12 A @ 28V
Standards
CE Certified, CSA Certified, UL Listed
Status Indicator
LED Indicator, Mechanical Flag
Power Consumption - Relay
2.5 VA
Features
Indicator Light Relay Energised LED
Contact Material
Silver Alloy
HP @ 120V
1/3 hp
HP @ 240V
1/2 hp
Motor Rated
Yes
Series
Square D 8501K Series
Socket Code
C
Horsepower @ 120V AC
1/3 hp
Horsepower @ 240V AC
1/2 hp
Minimum Operating Temperature
-40 Degrees F
Response Time
20 msec
Compatible with Manufacturer Model Number
8501NR82
Pin Shape
Flat
Push-To-Test Method
No Button
Maximum Switching Voltage
300V AC, 30V DC
Maximum Operating Temperature
131 Degrees F
Sealing
Enclosed
Power Consumption
2.5 VA
Compatible Manufacturer Part Number
8501NR82
Compatible Manufacturer Model Number
8501NR82
Operating Time
20 ms - pick-up || 20 ms - drop-out
Switching Voltage
300 V AC; 30 V DC
For Manufacturer Part Number
8501NR82
Compatible with Mfr. Model Number
8501NR82

Description

General Purpose Relay, Base Shape Square, Coil Voltage 120V AC, Contact Form 3PDT, Current Rating 10 A, Electrical Connection Quick-Connect, Flat Pin Width 0.189 in, Number of Pins 11, Pin Shape Flat, Sealing Enclosed, Status Indicator LED Indicator, Mechanical Flag, Contact Rating (AC) 12 A @ 240V, Contact Rating (DC) 12 A @ 28V, Horsepower @ 120V AC 1/3 hp, Horsepower @ 240V AC 1/2 hp, Mounting Style Socket, Push-To-Test Method No Button, Body Depth 1.4 in, Body Height 2.25 in
