This item is Discontinued.
Telemecanique Sensors Limit Switch, Plunger, Roller, SPDT, 10A @ 240V AC, Actuator Location: Top 9007MS03S0054

Limit Switch, Plunger, Roller, SPDT, 10A @ 240V AC, Actuator Location: Top (Discontinued)

  • Mfr # 9007MS03S0054
  • Zoro # G0561255
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
9007MS03S0054
Zoro #
G0561255
UPC #
785901753124
Country of Origin
Mexico

Dimensions

Body Depth - Limit Switch
0.62 in
Width
1.56 in
Body Height - Limit Switch
1.75 in

Details

Item
Limit Switch
Basic Actuator Style - Limit Switch
Plunger
Actuator Style - Limit Switch
Plunger, Roller
Contact Form- Switches
SPDT
Actuator Location - Limit Switch
Top
AC Contact Rating - Limit Switch
10A @ 240V
Amps
10
Body Style (Limit Switch)
fixed
Body Material
cast zinc, metal
Special Features
traverse approach, 2 directions
Operating Temp. Range
-40-220 Degrees F
Series
9007MS
NEMA Rating
NEMA 1 Nema type 250, NEMA 2 Nema type 250, NEMA 4 Nema type 250, NEMA 6 Nema type 250, NEMA 6P Nema type 250
Actuator Style
Cross Roller Plunger
Contact Form
Form C
Certification
UL, CE, CSA
IP Rating
IP67 conforming to IEC 60529
Movement
linear
Standards
E78403, LR 25490 Class 32 11 03; CE, UL, CSA
Contact Material
silver contacts
Electrical Connection
male connector M12 micro DC type 4 pins bottom
Vibration Resistance
10 gn 75-1200 Hz)IEC 60068-2-6
Shock Resistance
35 gn 9 ms IEC 60068-2-27
Electrical Durability
100000 cycles
Weight
1.2 lb(US)
Head Type
plunger head
Contact Action
snap action
Mechanical Durability
10000000 cycles
Actuation Type
by 30 Degree cam
Operating Force - Maximum
80 ozf
Number Of Poles
1
Type Of Operator
spring return cross roller plunger steel

Description

Limit Switch
