  15. Limit Switch, Plunger, Spring Return, SPDT, 10A at 240V AC, Actuator Location: Top
Telemecanique Sensors Limit Switch, Plunger, Spring Return, SPDT, 10A at 240V AC, Actuator Location: Top 9007MS09S0206 - main

Limit Switch, Plunger, Spring Return, SPDT, 10A at 240V AC, Actuator Location: Top

  • Mfr # 9007MS09S0206

  • Zoro # G0561289

product price: $162.99
/ea
Free Shipping & Returns

Key Features

Basic Actuator Style - Limit Switch
Plunger
Actuator Style - Limit Switch
Plunger, Spring Return
Contact Form- Switches
SPDT
Actuator Location - Limit Switch
Top
AC Contact Rating - Limit Switch
10A @ 240V
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
9007MS09S0206
Zoro #
G0561289
UPC #
785901157793
Country of Origin
Mexico

Dimensions

Width
1.56 in
Body Height - Limit Switch
1.75 in
Body Depth - Limit Switch
0.62 in

Details

Item
Limit Switch
Basic Actuator Style - Limit Switch
Plunger
Actuator Style - Limit Switch
Plunger, Spring Return
Contact Form- Switches
SPDT
Actuator Location - Limit Switch
Top
AC Contact Rating - Limit Switch
10A @ 240V
Amps
10
Certification
CE, UL, CSA
Body Material
cast zinc, metal
Contact Material
silver contacts
Body Style (Limit Switch)
fixed
NEMA Rating
NEMA 1 Nema type 250, NEMA 2 Nema type 250, NEMA 4 Nema type 250, NEMA 6 Nema type 250, NEMA 6P Nema type 250
Electrical Connection
pre-wired cable side
Standards
E78403, LR 25490 Class 32 11 03; CSA, CE, UL
IP Rating
IP67 conforming to IEC 60529
Contact Form
Form C
Operating Temp. Range
-40-220 Degrees F
Special Features
vertical approach, 1 direction
Series
9007MS
Movement
linear
Actuator Style
Plunger
Vibration Resistance
10 gn 75-1200 Hz)IEC 60068-2-6
Contact Action
snap action
Head Type
plunger head
Actuation Type
on end
Weight
1.2 lb(US)
Shock Resistance
35 gn 9 ms IEC 60068-2-27
Mechanical Durability
10000000 cycles
Electrical Durability
100000 cycles
Operating Force - Maximum
80 ozf
Number Of Poles
1
Type Of Operator
spring return plunger stainless steel adjustable

Description

Limit Switch
