  8. Limit Switch, Roller Lever, Rotary, 1NC/1NO, 3A at 240V AC, Actuator Location: Side
Telemecanique Sensors Limit Switch, Roller Lever, Rotary, 1NC/1NO, 3A at 240V AC, Actuator Location: Side XCKP2118M12 - main

Limit Switch, Roller Lever, Rotary, 1NC/1NO, 3A at 240V AC, Actuator Location: Side

  • Mfr # XCKP2118M12

  • Zoro # G0390652

product price:  $100.99
/ea
Free Shipping & Returns

Key Features

Basic Actuator Style - Limit Switch
Rotary
Actuator Style - Limit Switch
Roller Lever, Rotary
Contact Form- Switches
1NC/1NO
Actuator Location - Limit Switch
Side
AC Contact Rating - Limit Switch
3A at 240V
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
XCKP2118M12
Zoro #
G0390652
UPC #
785901931171
Country of Origin
France

Dimensions

Width
1.22"
Roller Width
0.22 in
Depth
1.18"
Actuator Length
1.3 in
Body Depth - Limit Switch
1.18 in
Actuator Length - Limit Switch
1.3 in
Height
2.56"
Body Height - Limit Switch
2.56 in
Roller Dia.
0.75 in
Body Width - Limit Switch
1.22 in
Body Depth
1.18 in
Body Height
2.56 in
Roller Diameter
0.75 in
Overall Width
1.22 in
Manufacturer Warranty Length
18 mo
Body Width
1.22 in
Mounting Hole Diameter
0.17 in
Overall Height
2.56 in
Overall Depth
1.18 in

Details

Item
Limit Switch
Basic Actuator Style - Limit Switch
Rotary
Actuator Style - Limit Switch
Roller Lever, Rotary
Contact Form- Switches
1NC/1NO
Actuator Location - Limit Switch
Side
AC Contact Rating - Limit Switch
3A at 240V
DC Contact Rating - Limit Switch
3A at 240V
Body Style - Limit Switch
Miniature
Mounting - Limit Switch
Surface
Body Material
plastic
Operating Temp. Range
-13 Degrees to 158 Degrees F
Basic Actuator Style (Limit Switch)
Rotary
Actuator Style (Limit Switch)
Rotary, Roller Lever
Mounting Hole - Limit Switch
(2) 0.17 in dia
Series
XCKP
Boot Sealed Actuator (Limit Switch)
No
Body Style (Limit Switch)
Miniature
DC Contact Rating
3 A @ 240 V
Travel
90 Degrees
Roller Material
Thermoplastic
Movement
CCW, CW
Electrical Connection
4-Pin M12 Connector
Contact Form
1NO/1NC
NEMA Rating
1, 12, 13, 2, 4, 6
Arm Material
Metal
Voltage Rating
240VAC/DC
Mounting Hole Pattern - Limit Switch
2 Hole Horizontal
Contact Form - Limit Switch
1NC/1NO
Wiring Entry
Connector
Stem Thread - Limit Switch
No Stem
Limit Switch Style
General Purpose Limit Switch
AC Contact Rating
3 A @ 240 V
Actuator Location (Limit Switch)
Side
IP Rating
IP66, IP67
Standards
CE, CSA, UL Listed
Mounting Hole Spacing - Limit Switch
0.75 in
Actuator Location
Side
Actuator Style
Roller Lever Plunger
Boot Sealed Actuator - Limit Switch
No
Amps
3
Operating Force
0.9 in-lb
Head Material
zamak
Certification
CSA || UL || CCC
Special Features
lateral approach, 2 directions
Actuation Type
by 30° cam
Contact Action
snap action
Electrical Durability
5000000 cycles, DC-13, 120 V, 4 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C || 5000000 cycles, DC-13, 24 V, 10 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C || 5000000 cycles, DC-13, 48 V, 7 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C
Short Circuit Protection
4 A cartridge fuse gG
Shock Resistance
50 gn 11 ms IEC 60068-2-27
Vibration Resistance
25 gn 10-500 Hz)IEC 60068-2-6
Mechanical Durability
10000000 cycles
Head Type
rotary head
Min. Actuation Velocity Horizontal
1.5 m/s
Number Of Poles
2
Type Of Operator
spring return roller lever thermoplastic
NEMA Enclosure Rating
1, 12, 13, 2, 4, 6
Operating Torque - Maximum
0.9 in-lb
Mounting Hole Horizontal Center to Center Distance
19 mm
Resistance Properties
Shock Resistant, Vibration Resistant
Directional Movement
CCW/CW
Mounting Style
Surface
Operating Temperature - Minimum
-13 Degrees F
Boot Sealed Actuator
No Boot Included
Number of Mounting Holes
2
Operating Temperature - Maximum
158 Degrees F

Description

Limit Switch, Actuator Style - Limit Switch Roller Lever, Rotary, Actuator Location - Limit Switch Side, AC Contact Rating - Limit Switch 3A @ 240V, DC Contact Rating - Limit Switch 3A @ 240V, Contact Form- Switches 1NC/1NO, Actuator Length - Limit Switch 1.3 in, Body Height - Limit Switch 2.56 in, Body Width - Limit Switch 1.22 in, Body Depth - Limit Switch 1.18 in, Boot Sealed Actuator - Limit Switch No, Body Style - Limit Switch Miniature, NEMA Rating 1, 12, 13, 2, 4, 6
