Telemecanique Sensors Safety Monitoring Relay, Panel XCSLF3737413 - main

Safety Monitoring Relay, Panel

  • Mfr # XCSLF3737413

  • Zoro # G6627205

product price: $655.99
/ea
Free Shipping & Returns

Key Features

Actuator Length
Key Dependent
Width
1.71 in
IP Rating
IP66
AC Contact Rating
4 A @ 300 V
Series
XCSLF
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
XCSLF3737413
Zoro #
G6627205
UPC #
785901133575
Country of Origin
Indonesia

Dimensions

Actuator Length
Key Dependent
Width
1.71 in
Conduit Size
1/2 in NPT
Height
8.1 in
Depth
2.01 in
Overall Width
1.73 in
Overall Depth
4.45 in
Overall Height
8.07 in
Manufacturer Warranty Length
18 mo

Details

Item
Safety Interlock Switch
IP Rating
IP66
AC Contact Rating
4 A @ 300 V
Series
XCSLF
Input Voltage
24VAC
Contact Configuration
3NO/1NC Aux.
Body Material
Zamak
Coil Volts
24VAC/DC
For Use With
Mfr. No. XCSZ01, XCSZ02, XCSZ03, XCSZ05
Standards
CSA C22.2 No 14, EN 1088/ISO 14119, EN/IEC 60204-1, EN/IEC 60947-5-1, EN/IEC 62061, EN/ISO 13849-1, UL 508
DC Contact Rating
3 A @ 300 V
NEMA Rating
12, 4, 4X
Environmental Protection
IP67
Connection Type
1/2 in NPT Conduit
Power Consumption
5.4W
Description/Special Features
Dust Tight and Corrosion Resistant (Indoor/Outdoor) Enclosure, Water Tight
Contact Load Rating
2.5A
Operating Force
4.5 lb
Mounting
Panel
Head Material
Zamak
Contact Form
1NO/2NC
Operating Temp. Range
-13 Degrees to 158 Degrees F
Mechanical Operating Durability
30,000
NEMA Enclosure Rating
12, 4, 4X
Resistance Properties
Corrosion Resistant, Dust Resistant, Shock Resistant, Vibration Resistant, Watertight
Circuitry Action
Slow Action
Electrical Connection
1/2 in NPT Conduit
Operating Temperature - Maximum
158 Degrees F
Actuating Key Type
Pivoting, Flat
Actuator Material
Plastic
Operating Temperature - Minimum
-13 Degrees F
Head Type
key operated turret head
Positive Opening
with NC contact
Safety Level
can reach category 4 with the appropriate monitoring system and correctly wired EN/ISO 13849-1 || can reach PL = e with the appropriate monitoring system and correctly wired EN/ISO 13849-1 || can reach SIL 3 EN/IEC 61508
[Ui] Rated Insulation Voltage
300 VUL 508 || 300 VCSA C22.2 No 14 || 250 V 3)EN/IEC 60947-1
Material
metal
Electrical Shock Protection Class
class I EN/IEC 61140
Component Name
XCSLF
Maximum Actuator Forcible Withdrawal Rtc
3000 N
Product Or Component Type
safety switch
Signalling Circuit Type
AC/DC
Cable Entry
3 entries tapped 1/2" NPT
Resistance To Mechanical Impact
9.6 J against the partition || 6.4 J without partition
Ambient Air Temperature For Storage
-40-70°C
[Ie] Rated Operational Current
0.55 A 24 V, DC-13, R300 EN/IEC 60947-5-1 || 0.75 A 240 V, AC-15, C300 EN/IEC 60947-5-1
Minimum Switching Voltage
17 V
Shock Resistance
10 gn 11 ms IEC 60068-2-27
Ambient Air Temperature For Operation
-25-60°C
[Ithe] Conventional Enclosed Thermal Current
4A
Contact Operation
slow-break, break before make
Mechanical Durability
30000 cycles
Minimum Actuation Speed
0.01 m/s
Maximum Actuation Speed
0.5 m/s
Supply Voltage Type
AC/DC
Vibration Resistance
5 gn 10-500 Hz)IEC 60068-2-6
Local Signalling
for actuator withdrawn 1 LED (orange) || for actuator inserted and locked 1 LED (green)
Contacts Type And Composition
2 NC + 1 NO
Load Factor
1
[Uimp] Rated Impulse Withstand Voltage
4 kV EN/IEC 60947-5-1
[Us] Rated Supply Voltage
24 V - 15...10 %
Maximum Load Current
<= 15 A
Minimum Switching Current
10 mA at 20°C
Solenoid Contacts Type And Composition
2 NC + 1 NO slow-break, break before make)
Product Certifications
UL || CSA || TUV
Short-Circuit Protection
4 A cartridge fuse gG (gl) || 6 A fast blow
Supply Frequency
50/60 Hz
Design
slim
Signalling Circuit Voltage
24 V
Ip Degree Of Protection
IP66 conforming to EN/IEC 60529 and EN/IEC 60947-5-1
Number Of Poles
3
Protective Treatment
TC
Maximum Operating Rate
10 cyc/mn for maximum durability
Electromagnet Interlocking
by mushroom head push-button turn to release for escape release || locking on de-energisation and unlocking on energisation of solenoid
Minimum Actuator Force For Extraction
20 N

Description

Safety Interlock Switch, Contact Form 1NO/2NC, Actuator Length Key Dependent, Connection Type 1/2 in NPT Conduit, AC Contact Rating 4 A @ 300 V, Series XCSLF, DC Contact Rating 3 A @ 300 V, Height 8.1 in, Width 1.71 in, Depth 2.01 in, NEMA Rating 12, 4, 4X, IP Rating IP66, Operating Temp. Range -13 Degrees to 158 Degrees F, Conduit Size 1/2 in NPT, Body Material Zamak, Head Material Zamak, Description/Special Features Dust Tight and Corrosion Resistant (Indoor/Outdoor) Enclosure, Water Tight
