Thermocouple Ext Wire, K, 20AWG, Str, 50Ft

Tempco Thermocouple Ext Wire, K, 20AWG, Str, 50Ft ECA00080
Tap to zoom
Hover or click to zoom
$276.43
  • Wire Size: 20 AWG
  • Length: 50 ft
  • Jacket Color: Silver Over Red/Yellow
See full product details
This item ships free.

Total: $276.43

Tempco #ECA00080 Specifications

  • Wire Size: 20 AWG
  • Length: 50 ft
  • Jacket Color: Silver Over Red/Yellow
  • Number of Conductors: 2
  • Color Code: Yellow Positive/Red Negative
  • Length - Wire and Cable: 50 ft.
  • Ambient Temp. Limits: 900 Degrees F
  • Wire Type: K
  • Insulation Material - Wire and Cable: Nylon
  • Wire Size - Wire and Cable: 20 AWG
  • Wire Type - Wire and Cable: K
  • Wire and Cable Item: Thermocouple Cable Assemblies
  • Insulation: BX Armor Over Glass Filled Nylon
  • Termination Type - Wire and Cable: Standard Jack, Standard Plug
  • Termination Type: Standard Jack and Standard Plug
  • Solid / Stranded: Stranded
  • Item: Thermocouple Cable Assemblies
  • Termination Type (Wire and Cable): Standard Jack, Standard Plug
  • Wire Size (Wire and Cable): 20 AWG
  • Length (Wire and Cable): 50 ft.
  • Plug or Connector Type: Standard
  • Thermocouple Type: K
  • Material: Glass Filled Nylon
  • Color: Silver
  • Length (Straight Wireway): 50 ft
  • Compatible Grainger Part Number: 3AEX9, 3AEY4, 3AEY5, 3AEY6, 3AEZ2, 3AEZ3, 3AEZ4, 3AEZ5, 5FYH0, 5FYH1, 5FYH2, 5FYH3, 5FYH4, 5FYH6, 5FYH7, 5ZY12, 5ZY13, 6THW7
  • Plug/Connector Type: Standard
  • Extension Cable Length: 50 ft
  • For Sensor Type: Type K
  • Maximum Temperature: 900 Degrees F/482 Degrees C
  • Product Type: Extension Lead
  • Extension Construction: BX Armor Over Glass Filled Nylon
  • Compatible Brand and Series: All Type K Thermocouples
  • Maximum Temperature F: 900 Degrees F
  • Maximum Temperature C: 482 Degrees C
  • Characteristics: 20 ga Stranded Thermocouple Wire with 0.270 in OD SS Armor Over Braid, Connector: Type K Std Plug, Jack Made of Nylon Filled Thermoplastic
  • Maximum Temperature °F: 900 Degrees F
  • Maximum Temperature °C: 482 Degrees C
  • Country of Origin (subject to change): United States

Description

Extension Lead, Thermocouple Type K, Standard Plug or Connector Type, Length 50 ft, Color Silver, Connector Type BX Armor Over Glass Filled Nylon, Material Glass Filled Nylon
