  5. Power Inverter and Battery Charger, Pure Sine Wave, 6,000 W Peak, 3,000 W Continuous, 1 Outlets
Tripp Lite Power Inverter and Battery Charger, Pure Sine Wave, 6,000 W Peak, 3,000 W Continuous, 1 Outlets RV3012OEM - main

Power Inverter and Battery Charger, Pure Sine Wave, 6,000 W Peak, 3,000 W Continuous, 1 Outlets

  • Mfr # RV3012OEM

  • Zoro # G0566146

product price:  $2,241.99
/ea
Free Shipping & Returns

Key Features

Peak Output Power
6,000 W
Continuous Output Power
3,000 W
Inverter Output Form
Pure Sine Wave
Inverter Input Voltage
12V DC; 120V AC
Inverter Output Voltage
120V AC
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
RV3012OEM
Zoro #
G0566146
UPC #
037332117427
Country of Origin
China

Dimensions

Inverter Width
11.5 in
Width
11-1/2"
Charger Width
11.5 in
Charger Depth
16.8 in
Inverter Depth
16.75 in
Depth
16-3/4"
Inverter Height
9.75 in
Charger Height
9.8 in
Height
9-3/4"
Unit Dimensions (hwd / in.)
9.750 x 11.500 x 16.750
Input Cord Length Details
DC INPUT: User supplies cabling. 0 gauge or larger (see manual). AC INPUT: hardwire

Details

Item
Power Inverter and Battery Charger
Peak Output Power
6,000 W
Continuous Output Power
3,000 W
Inverter Output Form
Pure Sine Wave
Inverter Input Voltage
12V DC; 120V AC
Inverter Output Voltage
120V AC
Outlet Type
Hardwired
DC Connection
Bolt Down Terminals
Number of Outlets
1
Automatic/Manual
Automatic
Nominal Output Power
3,000 W
Case Material
Steel
Charger Output Voltage
120V AC
Features
Expandable Runtime; Overload Protection
Charger Input Voltage
120V AC/12V DC
Standards
Tested to UL458 (USA) and CSA (Canada)
Charger Output Amps
140 A
Max. Input Current
Full continuous load - 282 A at 12V DC; 40 A at 120V AC with full inverter and charger load
Inveter Output Voltage
120V
Output Frequency
60 Hz
Input Voltage
12VDC
Output Voltage
120VAC
Charger Input Current
140 A
Charger Output Current
140 A
Package Contents
PowerVerter RV RV3012OEM Charger DC-to-AC Power Inverter, RV3012OEM Inverter/Charger, Instruction manual with warranty information
Product Line
PowerVerter
Product Series
RV
Maximum Frequency
60 Hz
Product Name
PowerVerter RV RV3012OEM Charger DC-to-AC Power Inverter
Voltage Compatibility (VAC)
120
Load Sensing
Optional load sense function enables automatic inverter shutoff and startup as connected equipment is powered off and on. Front panel load sense potentiometer can be set to shutoff or turn on inverter power in response to loads of any level, up to 150 watts.
Package Includes
RV3012OEM Inverter/Charger;Instruction manual with warranty information
Expandable Runtime
Yes
AC Suppression Joule Rating
450
Switches
3-position on/off/remote switch enables simple on/off power control plus auto/remote setting that enables distant on/off control of the inverter system when used in conjunction with APSRM4 accessory (sold separately) in inverter mode. In AC uninterruptible power mode, "auto/remote" setting enables automatic transfer from line power to battery power - to maintain continuous AC power to connected loads.
Battery Pack Accessory (Optional)
98-121 sealed lead acid battery (optional)
Frequency Compatibility
60 Hz
Material of Construction
Steel
Nominal Output Voltage(s) Supported
120V
Front Panel LEDs
Set of 6 LEDs offer continuous status information on load percentage (6 levels reported) and battery charge level (7 levels reported). See manual for sequences.
Output Frequency Regulation
60 Hz (+/- 0.3 Hz)
Output Voltage Regulation
LINE POWER (AC): Maintains 120V nominal sine wave output from line power source. INVERTER POWER (AC): Maintains PWM sine wave output voltage of 120 VAC (+/-5%).
Voltage Compatibility (VDC)
12
Maximum Input Amps / Watts
DC INPUT: Full continuous load - 282A at 12VDC. AC INPUT: 40 amps total (20A line 1 / 20A line 2) at 120VAC with full inverter and charger load (25A max charger-only from line 1 / combined input load to support charger and AC output is automatically controlled
Low Voltage Transfer to Battery Power
In AC "auto" mode, inverter/charger switches to battery mode as line voltage drops to 75V (user adjustable to 85, 95, 105V - see manual)
Recommended Electrical Service
DC INPUT: Requires 12VDC input source capable of delivering 290A for the required duration (when used at full continuous capacity - DC requirements increase during Over-Power and Double-Boost operation).
Nominal Input Voltage(s) Supported
120V AC
Overload Protection
Includes 30A input breaker dedicated to the charging system and 2 branch rated 20A output load breakers
Transfer Time (Line Power to Battery Mode)
16.6 milliseconds (typical - compatible with many computers - verify transfer time compatibility of loads for UPS applications)
Form Factors Supported
Mounting slots enable permanent placement of inverter on any horizontal surface (see manual for additional mounting information)
LVC (Low Voltage Cut-Off)
10VDC +/-3%
High Voltage Transfer to Battery Power
In AC "auto" mode, inverter/charger switches to battery mode as line voltage increases to 135V (user adjustable to 145 - see manual)
Battery Charge
35A / 140A (selectable)
Output Receptacles
Hardwire
DC System Voltage (VDC)
12
Product Certifications
CSA (Canada); UL 458
Relative Humidity
0%-95% Non-Condensing
Cooling Method
Fan

Description

Inverter and Battery Charger, Inverter Output Form Pure Sine Wave, DC Connection Input Terminals, Continuous Output Power 3,000 W, Peak Output Power 6,000 W, Charger Input Voltage 120V AC/12V DC, Charger Output Voltage 120V AC, Case Material Steel, Cooling Method Fan, Charger Height 9.8 in, Charger Width 11.5 in, Charger Depth 16.8 in, Inverter Height 9.75 in, Inverter Width 11.5 in, Inverter Depth 16.75 in, Automatic/Manual Automatic, Charger Input Current 140 A
