- MFR #
- PV3000GFCI
- Zoro #
- G3291251
- UPC #
- 037332146595
- Country of Origin
- China
- Item
- Power Inverter
- Peak Output Power
- 6,000 W
- Continuous Output Power
- 3,000 W
- Inverter Output Form
- Modified Sine Wave
- Inverter Input Voltage
- 12V DC
- Inverter Output Voltage
- 120V AC
- Outlet Type
- GFCI
- DC Connection
- Input Terminals
- Number of Outlets
- 4
- Nominal Output Power
- 3,000 W
- Includes
- 25 ft Remote Cable, Remote Control LED/Switch Module (APSRM4)
- Case Material
- Aluminum, Steel
- Standards
- OSHA 1926.404 (b) (ii)
- Max. Input Current
- Full continuous load - 286 A at 12V DC; No load - 2.6 A at 12V DC; Shutdown / load sense mode - less than 500 mA
- Application
- Coffee Makers, DVD Players, Game Systems, Microwaves, Office Equipment, Power Tools, TVs
- Temp. Range
- 32°F to 104°F
- Features
- Battery Charge Level LED, Connected Load Level LEDs, Daisy-Chain Capability, Dual Connections, Grooved Cooling Surface, Low Voltage Alarm/Shutdown, Operating Mode Switch Controls Inverter Operation, Remote Control LED/Switch Module
- Inveter Output Voltage
- 120V
- Output Frequency
- 60 Hz
- Minimum Operating Temperature
- 32 Degrees F
- NEMA Rating
- NEMA 5-15R
- Fused
- Yes
- Input Current
- 286 A at 12V DC, 2.6 A at 12V DC, Less Than 500 mA
- Output Form
- Modified Sine Wave
- Maximum Operating Temperature
- 104 Degrees F
- Type of Indicator
- LED
- Input Connection
- Input Terminals
- Output Connection
- (4) NEMA 5-15R
- Input Voltage
- 12V DC
- Output Voltage
- 120V AC
- Maximum Frequency
- 60 Hz
- Product Line
- PowerVerter
- Product Color
- Gray
- Product Name
- PowerVerter PV3000GFCI DC-to-AC Power Inverter
- Package Contents
- PowerVerter PV3000GFCI DC-to-AC Power Inverter, Remote Control LED/Switch Module, 25-ft. Remote Cable, Instruction Manual
- Audible Alarm
- Dual function alarm indicates overload conditions or low DC input voltage of 10.5V or less.
- Output Receptacles
- (4) 5-15R
- Form Factors Supported
- Mounting slots enable permanent placement of inverter on any horizontal surface (see manual for additional mounting information)
- Operating Temperature
- 32 to 104 F (0 to 40 C)
- Frequency Compatibility
- 60 Hz
- Nominal Output Voltage(s) Supported
- 120V
- Output Voltage Regulation
- Maintains PWM sine wave output voltage of 115 VAC (+/- 8 VAC)
- Output Frequency Regulation
- 60 Hz (+/- 3 Hz)
- Package Includes
- PV3000GFCI Inverter;Remote control LED/switch module (APSRM4);25-ft. (7.62 m) remote cable;Warranty information;Instruction manual
- Overload Protection
- Automatic overload protection shuts down inverter system in the event of overloads. Output is protected by 2 built-in 20A circuit breakers (each controlling power to 2 outlets). Inverter and electrical system are further protected via set of 6 40A automotive input fuses.
- Voltage Compatibility (VDC)
- 12
- DC System Voltage (VDC)
- 12
- Recommended Electrical Service
- Requires 12VDC input source capable of delivering 286A for the required duration (when used at full capacity). For automotive applications, professional hardwire installation with 500A battery system fusing is recommended.
- Material of Construction
- Aluminum, Steel
- Grounding
- Grounding lug grounds the inverter to vehicle or earth ground - user supplies cabling
- Maximum Input Amps
- 286
- Switches
- 3 position rocker switch enables on/off power control, plus remote setting which enables inverter to be remotely powered on or off when used in conjunction with included APSRM4 module.
- Relative Humidity
- 0%-95% Non-Condensing
- Real Power Rating
- 6,000 W
