- Item
- Power Strip
- Type
- Surge
- Total Number of Outlets
- 7
- Receptacle Configuration
- 5-15R
- Plug Configuration
- 5-15P
- Color
- Light Gray
- Gauge/Conductor
- 14/3
- Standards
- Approvals RoHS; cUL / CSA (Canada); Exceeds IEEE 587 category A&B specifications; FCC Part 68 (Communications); Industry Canada (Communications); UL1363 (Power Tap); UL1449 3rd Edition (AC Suppression); UL497A (Communications)
- Circuit Breaker
- 1
- Medical Grade
- No
- NEMA Plug Configuration
- NEMA 5-15P
- Max. Amps
- 15A
- NEC Cord Designation
- SJT
- Power Indicator
- Yes
- Noise Attenuation
- Up to 20dB
- Hz
- 50/60 Hz
- Housing Material
- Plastic
- For Use With
- Desktop, Network Or Home Computing Application Requiring Ac and Dialup Or Dsl Modem Line Protection
- Telephone/Fax Surge Protection
- Yes
- Footnotes
- 2
- Voltage
- 120VAC
- NEMA Receptacle Configuration
- NEMA 5-15R
- Number of Transformer Outlets
- 3
- Mounting Style
- Keyhole
- Max. Surge Current
- 72 kA
- Communication Port
- (2) RJ11 Telephone
- Includes
- 6 ft Telephone Cord, Instruciton Manual with Warranty Information
- Number of Outlets
- 7
- Coax Surge Protection
- No
- Outlet Center Distance
- 29mm Standard and 48mm Transformer
- Rated Joules
- 1,080
- Medical Facility Use
- Outside Patient Care Areas (UL 1363)
- Outlet Surge Protection
- Yes
- Number of Outlet Rows
- 1
- Application
- Home and Office
- USB Charging Port
- 0
- Number of Conductors
- 3
- Trade Designation
- SJT
- Frequency
- 50/60 Hz
- Features
- Diagnostic LED(s), Integrated Keyhole Mounting Slots
- Watts
- 1800W
- Surge Energy Rating
- 1080 J
- Compatibility
- Ideal for any desktop, network or home computing application requiring AC and dialup or DSL modem line protection
- Package Contents
- Protect It! SUPER6TEL 7-Outlets 120V Surge Suppressor, 6-ft. telephone cord, Instruction manual with warranty information
- Output Voltage
- 120 V AC
- Maximum Line Current
- 15 A
- Certifications & Standards
- UL1449 (let through rating 330V), IEEE 587 Category A and B, UL1363, cUL, FCC Part 68, UL497A
- Input Voltage
- 120 V AC
- Power Handling
- 1800 VA
- Dataline Protection
- Phone
- Frequency Compatibility
- 50 / 60 Hz
- Package Includes
- SUPER6TEL Surge Suppressor;6-ft. (1.83 m) telephone cord;Instruciton manual with warranty information
- Mounting Holes or Slots
- Yes
- AC Suppression Joule Rating
- 1080
- EMI / RFI Filtering
- Up to 20 dB
- Input Cord Details
- SJT
- Circuit Breaker (amps)
- 15
- Material of Construction
- Plastic
- Output Receptacles
- (7) 5-15R
- AC Suppression Response Time
- < 1 ns
- Diagnostic LED(s)
- Yes
- Nominal Input Voltage(s) Supported
- 120V AC
- Protection Modes
- Includes full normal mode (H-N) and common mode (N-G / H-G) line suppression
- Diagnostic LED Details
- Built-in LED confirms suppressor "protection present" (green) status
- Maximum Surge Amps
- 72000
- Input Plug Features
- Right Angle
- Network (Ethernet) Protection
- No
- Outlet Orientation
- Single row of 5, plus 2 side mounted outlets
- Outlets Measurement (Center to Center)
- Between Standard Outlets = 29mm; Between Transformer Outlets = 48mm
- Number of Circuit Breakers
- 1
- Product Type
- Surge Protector Outlet Strip
- Maximum Current
- 15 A
- Plug Style
- Straight
- Rated Energy Absorption
- 1,080 J
- Medical Facility Use UL Rating
- UL 1363
- Maximum Surge Current
- 72 kA
