- VA Rating - UPS Systems
- 750.0 VA
- Item
- UPS System
- UPS Type
- Line Interactive
- Power Rating
- 750VA
- Mounting
- Desktop/Tower
- Wattage
- 300 W
- Input Voltage
- 120V AC
- Output Voltage
- 120V AC
- Backup Time (Half/Full Load)
- Up to 12 hr
- Outlet Type
- Surge
- Medical Grade
- Yes
- Number of Outlets
- 3
- Includes
- 90 Amp-Hour User-Replaceable Battery Module and Cabling, Medical Grade Mobile Power Supply, PowerAlert Software CD and USB Cable, Remote User Interface (RUI) and Cabling
- Ports
- USB
- Hz
- 60 Hz
- Phase
- Single
- Footnotes
- 4,14,18
- Fax/Modem Line Protection
- No
- Automatic Volts Regulation
- No
- Input Current
- 90 A
- Transfer Time
- 0 msec
- Display Type
- No Display
- Standards
- CSA-C22.2 No. 601.1, IEC 60601-1, RoHS, UL1778
- Green Environmental Attribute
- Product Contributes To Reducing Energy Consumption
- NEMA Plug Configuration
- 5-15P
- Special Features
- Poweralert Data-Saving Software
- NEMA Receptacle Configuration
- (3) 5-15R
- Voltage
- 120
- Input Connection
- 10 ft Cord with NEMA 5-15P-HG Plug
- Housing Material
- Metal
- Battery Type
- VRLA
- Voltage Compatibility (VAC)
- 120
- Voltage Compatibility (VDC)
- 12
- Nominal Input Voltage(s) Supported
- 120V AC
- Peak Output Capacity (Watts)
- 750
- Form Factors Supported
- Retrofits most standard medical cart configurations
- Battery Charge
- Equal to discharge time. Includes advanced 3-stage (10A) battery charger
- Material of Construction
- Power Supply and Battery Module: metal
- Switches
- On Remote User Interface (RUI): On/Off Switch and Alarm-Mute Switch
- DC System Voltage (VDC)
- 12
- Recommended Electrical Service
- 15A 120V
- Cooling Method
- Fan
- EMI / RFI AC Noise Suppression
- Yes
- Input Connection Type
- NEMA 5-15P-HG Hospital-Grade
- Audible Alarm
- Low Battery Alarm
- Full Load Runtime (min.)
- Up to 12 hours typical runtime in standard configuration. Runtime varies depending on battery condition and load
- Output (Watts)
- 300
- Nominal Output Voltage(s) Supported
- 120V
- Network Monitoring Port
- USB
- Front Panel LEDs
- On Remote User Interface (RUI): Output AC Power, Battery Charge Level and Battery Charging Status
- Continuous Output Capacity (Watts)
- 300
- Compatibility
- AFC, Anthro, Datalux, GCX, Hergo, Human scale, Jaco, Knurr, Stinger
- Package Contents
- Medical-Grade Mobile Power Retrofit Kit, Medical-Grade Mobile Power Supply, 90 amp-hour User-Replaceable Battery Module and cabling, PowerAlert Data-Saving Software CD and USB cable, Remote User Interface (RUI) and cabling, Mounting Hardware Kit and owner's ma
- Product Certifications
- IEC 60601-1; CAN/CSA-C22.2 No. 601.1; UL 1778
- Package Includes
- Medical-Grade Mobile Power Supply;90 amp-hour User-Replaceable Battery Module and cabling;PowerAlert Software CD and USB cable;Remote User Interface (RUI) and cabling;Mounting Hardware Kit and owner's manual with warranty information
- Pure Sine Wave Output
- No
- External Battery Compatible
- Not External Battery Pack Compatible
- Includes Battery
- Battery Included
- Battery Chemistry
- Valve Regulated Lead Acid
- Frequency
- 60 Hz
- Audible Alarm Conditions
- Low Battery
- Output Ports Included
- USB
- Manufacturer Warranty
- 3 yr Limited
- Data Line Protection
- No Data Line Surge Protection
- Number of Outlets - Surge Only
- 3
- Receptacle Configuration
- 5-15R
- Plug Configuration
- 5-15P
- Transfer Time - Maximum
- 0 msec
- Power Rating - Real
- 300 W
- Surge Suppression Rating
- 316 J
- Automatic Voltage Regulation
- No Automatic Voltage Regulation
- Run Time - Full Load
- 12 hr
- Number of Outlets - UPS
- 3
- Visible Indicator Light Conditions
- No Indicator Lights
- Input Current - Maximum
- 90 A
- Power Rating - Apparent
- 750 VA
