- Item
- UPS System
- UPS Type
- Line Interactive
- Power Rating
- 800VA
- Mounting
- Tower/Wall
- Wattage
- 475 W
- Input Voltage
- 120V AC
- Output Voltage
- 110/115/120V AC
- Backup Time (Half/Full Load)
- 11.5 min/3.5 min
- Outlet Type
- (1) Surge; (6) UPS/Surge
- Medical Grade
- No
- Number of Outlets
- 7
- Special Features
- Hot Swappable Batteries
- Automatic Volts Regulation
- Yes
- Ports
- TEL/DSL, USB
- VA Rating - UPS Systems
- 800.0 VA
- Green Environmental Attribute
- Product Contributes To Reducing Energy Consumption
- Input Current
- 12 A
- Footnotes
- USB and TEL/DSL
- NEMA Plug Configuration
- 5-15P
- Phase
- Single
- Transfer Time
- 2 to 4 msec
- NEMA Receptacle Configuration
- (7) 5-15R
- Display Type
- No Display
- Hz
- 60 Hz
- Fax/Modem Line Protection
- Yes
- Includes
- Interactive UPS, USB and Telephone Cable
- Standards
- CSA, FCC Part 15 Class B, NOM, RoHS, UL1778
- Operating Temp. Range
- 122°F (50°C)
- Battery Type
- Sealed Lead Acid (SLA)
- Capacity - Batteries
- 800 VA/475 W
- Housing Color
- Black
- Input Connection
- NEMA 5-15P Plug
- Housing Material
- PVC
- Primary Form Factor
- Tower
- Battery Recharge Rate (Included Batteries)
- Less than 4.5 hours from 10% to 90%
- Hot-Swap PDU options
- PDUB15 (2U / 8 5-15R outlets)
- Low Voltage Transfer to Battery Power (Setpoint)
- 89
- Installation Form Factors Supported with Included Accessories
- Tower
- Battery Replacement Description
- Hot-swappable, user replaceable batteries
- AC Mode Efficiency Rating (100% Load)
- 0.97
- Internal UPS Replacement Battery Cartridge
- RBC51
- High Voltage Transfer to Battery Power (Setpoint)
- 139
- Output AC Waveform (Battery Mode)
- PWM sine wave
- UPS AC Suppression Joule Rating
- 510
- Battery Access
- Battery access door
- Installation Form Factors Supported with Optional Accessories
- Wallmount ( UPSWM - tower mounting kit)
- Input Phase
- Single-Phase
- EMI / RFI AC Noise Suppression
- Yes
- Full Load Runtime (min.)
- 3.5 min. (475w)
- Audible Alarm
- Audible alarm indicates power-failure and low-battery conditions
- Output Voltage Regulation (Battery Mode)
- +/- 5%
- Individually Controllable Load Banks
- No
- Nominal Input Voltage(s) Supported
- 120V AC
- Alarm Cancel Operation
- Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate low-battery status
- LED Indicators
- 4 LEDs indicate line power, battery power, overload and battery low/replace status
- Battery Mode BTU / Hr. (Full Load)
- 631
- Communications Interface
- USB (HID enabled)
- Operating Temperature Range
- +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
- PowerAlert Software
- For local monitoring via the UPSâ„¢s built-in USB ports, download PowerAlert Local software at http://www.tripplite.com/poweralert
- Undervoltage Correction
- Input voltages between 89 and 105 are boosted by 14%
- AC Mode BTU / Hr. (Full Load)
- 24
- Half Load Runtime (min.)
- 11.5 min. (240w)
- Voltage Regulation Description
- Automatic voltage regulation (AVR) maintains line power operation with input voltage as low as 89
- Output Volt Amp Capacity (VA)
- 800
- Storage Temperature Range
- +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
- Communications Cable
- USB interface cable included
- Switches
- 2 Switches control off/on power status and alarm-cancel/self-test operation
- Relative Humidity
- 0 to 95%, non-condensing
- Expandable Runtime
- No
- Nominal Output Voltage(s) Supported
- 110V; 115V; 120V
- High Availability UPS Features
- Hot swappable batteries
- Rated input current (Maximum Load)
- 12A
- UPS Certifications
- Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category B (EMI)
- Network UPS Tools Compatibility
- NUT compatible. See the full list of Tripp Lite NUT compatible UPS systems at http://www.networkupstools.org/stable-hcl.html?manufacturer=Tripp Lite
- UPS Dataline Suppression
- 1 line TEL/DSL (1 in / 1 out); 10/100Base T Ethernet
- WatchDog Compatibility
- Supports Watchdog application, OS and hard-reboot restart options for remote applications
- Recommended Electrical Service
- 15A 120V
- UPS AC Suppression Response Time
- Instantaneous
- Output Watt Capacity (Watts)
- 475
- DC System Voltage (VDC)
- 12
- Cold Start (Startup in Battery Mode During a Power Failure)
- Cold-start operation supported
- Form Factor
- Tower
- Typical Battery Recharge Time
- 4 Hour
- Product Series
- VS
- Package Contents
- OMNIVS800 800VA UPS, USB and telephone cable, User manual with warranty information
- Battery Life
- 6 Year
- Maximum Operating Temperature
- 122°F (50°C)
- Battery Chemistry
- Valve Regulated Lead Acid
- Dataline Protection
- RJ-45
- Surge Energy Rating
- 480 J
- Status Indicators
- Line Power, Battery Power, Battery Low/Replace, Voltage Regulation operation
- Alarm
- On Battery, Utility Power Failure
- USB
- Yes
- Additional Information
- Automatic Voltage Regulation, Regulates brownouts as low as 83 volts back to usable levels without using battery power, Supports battery replacement via built-in access panel
- Waveform Type
- Pulse-width Modulated Sine Wave
- Load Capacity
- 800 VA/475 W
- Output Capacity (VA)
- 800
- Product Certifications
- CSA (Canada); NOM (Mexico); UL 1778
- Product Compliance
- FCC Part 15 Class B (USA)
- Package Includes
- OMNIVS800 Line Interactive UPS;USB and telephone cable;User manual with warranty information
- UPS Applications
- Home/Office Desktop; Retail/Point of Sale; Hospitality
- Output Capacity (Watts)
- 475
- Replacement Battery Part Number
- RBC51
- Operating Temperature - Minimum
- 32 Degrees F
- Number of Outlets - UPS
- 6
- Data Line Protection
- Includes Data Line Surge Protection
- Transfer Time - Minimum
- 2 msec
- Transfer Time - Maximum
- 4 msec
- Frequency
- 60 Hz
- Power Rating - Apparent
- 800 VA
- Includes Battery
- Battery Included
- Automatic Voltage Regulation
- Includes Automatic Voltage Regulation
- Number of Outlets - Surge Only
- 1
- External Battery Compatible
- Not External Battery Pack Compatible
- Audible Alarm Conditions
- Low Battery
- Run Time - Full Load
- 3.5 min
- Power Rating - Real
- 475 W
- Visible Indicator Light Conditions
- Battery Low, Overload, Power Status, Replace Battery
- Plug Configuration
- 5-15P
- Output Ports Included
- USB
- Manufacturer Warranty
- 3 yr Limited
- Operating Temperature - Maximum
- 104 Degrees F
- Input Current - Maximum
- 12 A
- Battery Recharge Time
- 4.5 hr
- Receptacle Configuration
- 5-15R
