Tycon Systems DC to DC Converter, 18-36V DC to 56V DC, 70VA, 0 Hz, DIN Rail, Metal TP-VRHP-2456 - main
Shop TYCON SYSTEMS

DC to DC Converter, 18-36V DC to 56V DC, 70VA, 0 Hz, DIN Rail, Metal

  • Mfr # TP-VRHP-2456

  • Zoro # G4584075

product price:  $190.99
/ea
Free Shipping & Returns

Key Features

Converts
18-36V DC to 56V DC
Enclosure Material
Metal
Mounting
DIN Rail
Frequency
0 Hz
Height
5.24 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
TP-VRHP-2456
Zoro #
G4584075
UPC #
810017122479
Country of Origin
Taiwan, Province of China

Dimensions

Height
5.24 in
Width
3 in
Depth
1-1/2 in

Details

Item
DC to DC Converter
Converts
18-36V DC to 56V DC
VA Rating
70VA
Enclosure Material
Metal
Mounting
DIN Rail
Frequency
0 Hz
Weight (Approximate)
12.80 oz
Maximum Output Current
1.25 A
Product Series
TP-VRHP
Package Contents
TP-VRHP-2456 DC Converter, DIN rail adapters
Device Supported
Security Device, Wireless Base Station, Remote Power System
Output voltage
56 V DC
Maximum Output Power
70 W
Isolation Voltage / Ohms
1500VDC Min. / 100M Ohms Min
Protections
Short Circuit, Overvoltage, Overload
DC Voltage Output
56VDC @ 1.25A
Operating temperature
- 22°F to 149°F ( - 30°C to +65°C)
Wire Gauge
12AWG Max
Maximum Power
70W
Ripple / Noise
2% / 5%
DC Input Voltage Range
+/ - 18 to 36VDC
Efficiency
>85%
Operating Humidity
0 to 90% RH
Load / Line Regulation
5% / 1%

Description

Voltage Converter 18-36VDC Input, 56VDC @ 1.25A 70W Regulated output, isolated
