Indexable Boring Bar, HM08Q SWLCL2, 7 in L, Heavy Metal, Trigon Insert Shape

  • Mfr # 940-000-043

  • Zoro # G9231966

product price:
$
351.99
/ea
Free Shipping & Returns

Key Features

Shank Material
Heavy Metal
Insert Shape
Trigon
Type
Turning
ANSI Number
HM08Q SWLCL2
Inscribed Circle
1/4"
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
940-000-043
Zoro #
G9231966
UPC #
-
Country of Origin
United States

Dimensions

Overall Length
7 in
Insert Thickness
0.0937"
Bar Dia.
0.500"
Shank Dia.
1/2 in
Insert Size
21.51
Min. Bore Dia.
0.5600 in
Wire Rope Length
7 in

Details

Item
Indexable Boring Bar
Shank Material
Heavy Metal
Insert Shape
Trigon
ANSI Code
HM08Q SWLCL2
Type
Turning
ANSI Number
HM08Q SWLCL2
Inscribed Circle
1/4"
Lead Angle
-5 Degrees
Rake
Positive
For Use With
WCMT 21.51
Min. Bore
0.560"
Cutting Edge Type
-5 Degrees
Style
Coolant-Thru
Left/Right Hand
Left Hand
Mounting Style
Screw Lock
Cutting Direction
Left Hand
Insert Holding Type
Screw On
Number of Inserts
1
Vibration Dampening
Yes
Coolant Fed
Coolant Through
Head Material
Heavy Metal
Insert Inscribed Circle
1/4 in
Insert Clearance Angle
7 Degrees
Insert Style
WCMT
Cutting Application
Boring
Side Cutting Edge Angle
-5 Degrees
Center to Cutting Tip
0.2810 in
Compatible Hardware
MTS-255 Insert Screw, T-7 Key

Description

Indexable Boring Bar, Insert Shape Trigon, Overall Length 7 in, HM08Q SWLCL2, 0.2810 in, MTS-255 Insert Screw, T-7 Key, Coolant Through, Boring, Left Hand
