3-Phase Belt Drive Motor, 2 HP, 56H Frame, 208-230/460V AC Voltage, 1,725 Nameplate RPM

  • Mfr # 8493P
  • Zoro # G0919823
product price:
$
823.99
/ea
Free Shipping & Returns

Key Features

Motor Design
3-Phase
Motor Enclosure Design
Open Dripproof
HP
2
No. of Speeds
1
RPM Range
1,701-1,800
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
8493P
Zoro #
G0919823
UPC #
786382110437
Country of Origin
Mexico

Dimensions

Shaft Dia.
5/8 in
Overall Length
12 11/16 in
Length Less Shaft
10 23/32 in
Body Dia.
6 1/4 in
Shaft Length
1 31/32 in
Body Diameter
6.3 in
Shaft Diameter
5/8 in
Frame Size
56H

Details

Item
Belt Drive Motor
Motor Design
3-Phase
Motor Enclosure Design
Open Dripproof
HP
2
No. of Speeds
1
RPM Range
1,701-1,800
Nameplate RPM
1,725
Voltage
208V AC to 230V AC, 460V AC
Frame
56H
Motor Mounting Type
Resilient
Motor Thermal Protection
Auto
Motor Service Factor
1.15
Voltage Compatibility
208V AC to 230V AC, 460V AC
Phase
Three
Motor Shaft Design
Keyed
Max. Ambient Temp.
40 Degrees C
Hz
60 Hz
Weight
26 lb
Insulation Class
B
Motor Enclosure Type
Open Drip Proof
Full Load Current @ 60 Hz
6.1-6.3/3.1 A
Drive Type
Belt Drive
Ambient Temperature - Maximum
40 Degrees C
Frequency
60 Hz
Shaft Design
Keyed
Product Type
Fan and Blower Motor
Nameplate Service Factor @ 60 Hz
1.15
Application
Fan/Blower
Number of Speeds
1

Description

Fan and Blower Motor, Three Phase, Motor Design Three-Phase, 2 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 208-230/460V AC, 6.1-6.3/3.1 A Full Load Amps, 56H Frame, 60 Hz Hz, Usable @ 208V Usable at 208V, Motor Service Factor 1.15, Motor Thermal Protection Auto, Ins. Class B, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Drip Proof, Motor Mounting Type Cradle Base, Shaft Length 1 31/32 in, Shaft Dia. 5/8 in
