This item is Discontinued.

Versilic Silicone Tubing, 7/16 In OD, 50 Ft ABX00022-GR

Silicone Tubing, 7/16 In OD, 50 Ft (Discontinued)

  • Mfr # ABX00022-GR
  • Zoro # G0500543
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
ABX00022-GR
Zoro #
G0500543
UPC #
-
Country of Origin
United States

Dimensions

Inside Dia.
5/16 in
Outside Dia.
7/16 in
Wall Thickness
0.06 in
Tube Length
50 ft
Tube Bend Radius
5/8 in
Outside Diameter
7/16 in
Inside Diameter
5/16 in
Overall Length
50 ft
Bend Radius
1 1/4 in

Details

Tube Material
Silicone
Tube Hardness
Shore A: 50
Material
Silicone
Max. Pressure
Not Rated
Color
Clear
Type
SPX-50
Tube Color
Translucent
Item
Tubing
Standards
ASTM D1599, ASTM D2240-91, ASTM D412-92, ASTM D624-91 Die B, ASTM D792-91, FDA 21 CFR 177.2600, NSF 51
Tensile Strength
1500 psi, 10.3 Mpa
Temp. Range
-112 Degrees to 350 Degrees F
System of Measurement
Inch
For Fluid Type
Beverages
Material Trade Number
SPX-50
Clarity
Semi-Clear
Maximum Operating Pressure
6 psi @ 320 Degrees F; 7 psi @ 73 Degrees F
Tubing Material
Silicone
Tradename Material
Versilon SPX-50
Elongation
250%
Features
Smooth Inner Bore
Material Trade Name
Versilon
For Environment
High Temperature
Maximum Operating Temperature
350 Degrees F
Hardness
Shore A 45 to 55
Autoclavable
Yes
Minimum Operating Temperature
-75 Degrees F
Application
Steam
Resistance Properties
High Temperature Resistant, Tear Resistant
Flexibility
Flexible
Flow Application
Analytical Instruments, Appliance Manufacturing, Beverage Dispensing Units, Cosmetic Production, Electronic Equipment, Environmental Remediation, Food and Dairy Processing
Tubing Hardness
Ultra Soft (Less than A60)

Description

Tubing, Application Steam, Color Clear, Hardness Shore A 45 to 55, Inside Diameter 5/16 in, Material Silicone, Material Trade Name Versilon, Material Trade Number SPX-50, Maximum Operating Pressure 6 psi @ 320 Degrees F; 7 psi @ 73 Degrees F, Maximum Operating Temperature 350 Degrees F, Outside Diameter 7/16 in, Overall Length 50 ft, PEX Type Not Applicable, Resistance Properties High Temperature Resistant, Tear Resistant
