Viega Check Valve, 7.18 in Overall L 29070 - main

Check Valve, 7.18 in Overall L

  • Mfr # 29070

  • Zoro # G810041900

product price: $792.99
/ea
Free Shipping & Returns

Key Features

Connection Type
Press x Press
Body Material
316 Stainless Steel
Cracking Pressure
0.5 psi
Overall Length
7.18 in
Pipe or Tube Size
1 1/2 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
29070
Zoro #
G810041900
UPC #
-
Country of Origin
Germany

Dimensions

Overall Length
7.18 in
Pipe or Tube Size
1 1/2 in
Length
7 3/16 in
Nominal Valve Size
1 1/2 in
Connection Size - Side 2
1 1/2 in
Connection Size - Side 1
1 1/2 in

Details

Connection Type
Press x Press
Body Material
316 Stainless Steel
Cracking Pressure
0.5 psi
Mechanism and Body Design
Inline
Body Material - Valves
316 Stainless Steel
Seal Material
EPDM
Seat Material
EPDM
Flow
155 gpm
Flow Design
Single
Spring Material
Stainless Steel
Item - Check Valves
Check Valve
Application - Valves
Chilled Water, Hot and Cold Water, Hydronic Heating Water
Item
Check Valve
Max. Temp. - Valves
250 Degrees F
Standards
Conforms to MSS SP-80, NSF 372 C.HOT
Min. Temp. - Valves
0 Degrees F
3-A Standard Compliance
Not Rated
Check Mechanism Material
Stainless Steel
NSF Certifications for Food and Drinking Water
NSF 61
Maximum Pressure - Operating
250 psi
Valve Body Style
Inline
Includes Counterweight
No Counterweight
Connection Type - Side 1
Press
Vacuum Service Rating
Not Rated
Coefficient of Volume (Cv)
41.3
Mounting Orientation
Horizontal, Vertical
Connection Type - Side 2
Press
Silent Check
Silent
Maximum Pressure - Steam
Not Rated
Operating Temperature - Maximum
250 Degrees F
Operating Temperature - Minimum
0 Degrees F
For Media
Chilled Water, Hot and Cold Water, Hydronic Heating Water
Valve Series
5174

Description

Check Valve

Restrictions
