Analog Output Module

This is an 8-channel analog output module from the WAGO I/O System 750 designed to generate standard voltage signals for controlling actuators in industrial automation systems. It provides precise analog output control with high resolution and electrical isolation. Specifications: -Model: 750-597 -Type: Analog output module (WAGO I/O System 750) -Function: 8-channel analog voltage output -Output Signal Range: 0-10 V DC / ±10 V DC -Number of Outputs: 8 analog channels -Resolution: 12-bit -Conversion Time: -13 ms (typical) -Output Type: Voltage -Load Impedance: ≥ 2 kohm -Isolation: 500 V (system/field isolation) -Supply Voltage: 24 V DC (field supply) -System Supply: 5 V DC via backplane -Current Consumption: -61 mA (system side) -Mounting: DIN rail (35 mm) -Connection Type: CAGE CLAMP spring terminals -Housing Material: Polycarbonate / Polyamide 6.6 -Protection Class: IP20 -Operating Temperature: 0 deg C to 55 deg C -Dimensions: 100 x 12 x 69 mm
