Fieldbus Coupler

This is a PROFIBUS DP fieldbus coupler from the WAGO I/O System 750 series used to connect distributed I/O modules to a PROFIBUS DP network. It automatically detects connected modules and creates a process image for communication with a PLC master system. Specifications: -Model: 750-333 -Type: Fieldbus coupler (PROFIBUS DP) -System: WAGO I/O System 750/753 -Communication Protocol: PROFIBUS DP (EN 50170) -Baud Rate: 9.6 kbit/s to 12 Mbit/s -Network Nodes: Up to 63 I/O modules per node -Process Image: Automatic configuration of inputs/outputs -Input/Output Capacity: Up to 244 bytes input / 244 bytes output process data -Bus Interface: PROFIBUS DP (9-pin D-sub connector) -Supply Voltage: 24 V DC -Current Consumption: -200 mA -Isolation: 500 V (system/field isolation) -Mounting: DIN rail (35 mm) -Connection Type: CAGE CLAMP spring terminals -Housing Material: Polycarbonate / Polyamide 6.6 -Protection Class: IP20 -Operating Temperature: 0 deg C to 55 deg C -Standards: EN 50170 compliant
