Indexable Boring Bar, SSII750860R, 8 in L, High Speed Steel, Triangle Insert Shape

  • Mfr # SSII750860R

  • Zoro # G3575949


product price: $318.99
/ea
Free Shipping & Returns

Key Features

Overall Length
8 in
Shank Material
High Speed Steel
Insert Shape
Triangle
ANSI Code
SSII750860R
Insert Size
3205
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
SSII750860R
Zoro #
G3575949
UPC #
4021169384875
Country of Origin
United States

Dimensions

Overall Length
8 in
Insert Size
3205
Shank Dia.
3/4 in
Min. Bore Dia.
0.9350 in
Shank Length
7.0010 in
Insert Cutting Edge Length
16.50mm
Cutting Height
0.0075 in

Details

Item
Indexable Boring Bar
Shank Material
High Speed Steel
Insert Shape
Triangle
ANSI Code
SSII750860R
Rake
-2 Degrees Axial, 0 Degrees Radial
Left/Right Hand
Right Hand
Lead Angle
30 Degrees
Type
Screw Clamping
Cutting Direction
Right Hand
Coolant Fed
Coolant Through
Insert Holding Type
Screw On
Center to Cutting Tip
0.5480 in
Compatible Hardware
T10 Insert Screw
Cutting Application
Grooving, Threading
ISO Number
SSII750860R
Side Cutting Edge Angle
30 Degrees
Number of Coolant Holes
1
Approach Angle
60 Degrees
Insert Style
TP
Insert Clearance Angle
11 Degrees
Number of Inserts
1
Measurement System
Fractional Inch

Description

Indexable Boring Bar, Insert Shape Triangle, Overall Length 8 in, SSII750860R, 60 Degrees , 0.5480 in, T10 Insert Screw, Coolant Through, Grooving, Threading, Right Hand
