  11. Indexable Drilling Insert, 1/4 in, 11 Degrees
Widia Indexable Drilling Insert, 1/4 in, 11 Degrees CPHB21205 - main

Indexable Drilling Insert, 1/4 in, 11 Degrees

  • Mfr # CPHB21205

  • Zoro # G4138158

product price: $14.29
/ea
Sold in multiples of 5 for $71.45

Key Features

Workpiece Compatibility
Cast Iron (K), Nonferrous (N), Stainless (M), Steel (P), Super Alloy (S)
Insert Size
21205
Grade
CG5
Inscribed Circle
1/4 in
Insert Style
CPHB
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
CPHB21205
Zoro #
G4138158
UPC #
-
Country of Origin
United States

Dimensions

Insert Size
21205
Nose Radius
0.007"
Insert Thickness
0.0750"
Dimension Type
Inch
Corner Radius
0.18mm
Thickness
1.90mm
Hole Dia.
2.80mm
Cutting Edge Length
6.45mm

Details

Item
Indexable Drilling Insert
Workpiece Compatibility
Cast Iron (K), Nonferrous (N), Stainless (M), Steel (P), Super Alloy (S)
Grade
CG5
Inscribed Circle
1/4 in
Insert Style
CPHB
Insert Shape
Diamond
Application
Small Hole Boring Positive Inserts
Non Ferrous (N) Compatibility
Yes
Stainless (M) Compatibility
Yes
Super Alloy (S) Compatibility
Yes
Cast Iron (K) Compatibility
Yes
Steel (P) Compatibility
Yes
Style
CPHB
Hardened (H) Compatibility
No
Cutting Direction
Neutral
Insert Material
Carbide
Chip-Breaker
No
Insert Application
Drilling
Coating
TiN
Relief Angle
11 Degrees
ISO Number
CPHB06T102
Shape
80 Degrees Diamond
Secondary Material Application ISO Code
K
Secondary Material Application
Cast Iron
Material - Machining
Carbide
Finish - Machining
TiN
Manufacturer Grade
CG5
ANSI Code
CPHB21205
Primary Material Application
Aluminum, Brass, Bronze, Copper, Magnesium, Nickel, Stainless Steel, Steel, Titanium
Primary Material Application ISO Code
M, N, P, S
Number of Cutting Edges
4
Measurement System
Decimal Inch
Finish
TiN

Description

Indexable Drilling Insert, Relief Angle 11 Degrees , TiN, ANSI Code CPHB21205, Corner Radius 0.18mm, Hole Dia. 2.80mm
