Widia Indexable Insert Drill, 1", TCF TCF0844R5SLR100C - main

Indexable Insert Drill, 1", TCF

  • Mfr # TCF0844R5SLR100C

  • Zoro # G3777320

product price:  $606.99
/ea
Free Shipping & Returns

Key Features

Diameter
1"
Ratio
5xD
Shank Length
2.2047 in
Mounting Style
Screw Clamp
Drilling Depth
4-1/4"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
TCF0844R5SLR100C
Zoro #
G3777320
UPC #
4050841106306
Country of Origin
United States

Dimensions

Diameter
1"
Shank Length
2.2047 in
Drilling Depth
4-1/4"
Overall Length
7.5407 in
Shank Dia.
1 in
Min. Drill Dia.
27/32 in
Max. Drilling Depth
4-1/4 in
Flute Length
5.1780 in
Depth x Dia. Ratio
5xD

Details

Item
Indexable Insert Drill
Ratio
5xD
Mounting Style
Screw Clamp
Cutting Direction
Right Hand
Number of Coolant Holes
2
ANSI Code
TCF0844R5SLR100C
Drilling Application
45 Degrees Corner, Blind Hole, Chain, Convex, Cross Hole, Half Cylindrical, Inclined Entry, Inclined Exit
Shank Type - Machining
Round with Flat and Side Lock
Coolant Fed
Coolant Through
Flanged Shank
Yes
ISO Number
TCF0844R5SLR100C
Central Insert Style
TCF
Spiral Direction
Right Hand
Toolholder Style
TCF
Number of Inserts
2
Flute Type
Slow Spiral
Measurement System
Fractional Inch

Description

Indexable Insert Drill, 5xD, Max. Drilling Depth 4-1/4 in, TCF0844R5SLR100C, TCF, Coolant Through
