Indexable Profiling End Mill, M1200 Series, High Speed Steel, 4.70mm Depth of Cut
Mfr # M1200HD080Z05HN07
Zoro # G3781450
product price:Â $941.99
/ea
Free Shipping & Returns
Key Features
Series
M1200
Overall Length
50.00mm
Depth of Cut
4.70mm
Material - Machining
High Speed Steel
Insert Size
0704
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
M1200HD080Z05HN07
Zoro #
G3781450
UPC #
4021169601880
Country of Origin
Czechia
Dimensions
Overall Length
50.00mm
Depth of Cut
4.70mm
Insert Size
0704
Max. Cutting Dia.
86.75mm
Arbor Dia.
27.00mm
Hub Outside Dia.
60.00mm
Details
Item
Indexable Profiling End Mill
Series
M1200
Material - Machining
High Speed Steel
Cutting Direction
Right Hand
Insert Shape
120 Degrees Hexagon
Rake
-7 Degrees Axial, -7 Degrees Radial
Coolant Fed
Coolant Through
Insert Style
HNGJ ANENLD
ANSI Code
M1200HD080Z05HN07
Compatible Hardware
Anti-Seize Lubricant, Insert Screw M4x0.7 x 10 T15, Torx Driver
ISO Number
M1200HD080Z05HN07
Number of Inserts
5
Features
First Choice for Low Depth of Cut Face Milling, Maximum Number of Teeth per Diameter, Twelve Cutting Edges
Insert Holding Type
Screw
Cutting Application
Face Milling, Side and Face Milling, Side/Shoulder Milling: Eased Chamfer
Max. Speed
7,900 RPM
Description
Indexable Profiling End Mill, Max. Cutting Dia. 86.75mm, Depth of Cut 4.70mm, Overall Length 50.00mm, ANSI Code M1200HD080Z05HN07, Compatible Hardware Anti-Seize Lubricant, Insert Screw M4x0.7 x 10 T15, Torx Driver, Coolant Fed Coolant Through, Cutting Application Face Milling, Side and Face Milling, Side/Shoulder Milling: Eased Chamfer
