Indexable Profiling End Mill, M1200 Series, High Speed Steel, 4.70mm Depth of Cut
Mfr # M1200HD400Z06S150HN07
Zoro # G3799930
product price:Â $1,011.99
/ea
Free Shipping & Returns
Key Features
Series
M1200
Overall Length
44.45mm
Depth of Cut
4.70mm
Material - Machining
High Speed Steel
Insert Size
0704
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowUnlock tax-exempt savings
Add Tax ExemptionSpecifications
Product Information
MFR #
M1200HD400Z06S150HN07
Zoro #
G3799930
UPC #
4021169603259
Country of Origin
India
Dimensions
Overall Length
44.45mm
Depth of Cut
4.70mm
Insert Size
0704
Max. Cutting Dia.
108.36mm
Arbor Dia.
1-1/2"
Hub Outside Dia.
93.00mm
Details
Item
Indexable Profiling End Mill
Series
M1200
Material - Machining
High Speed Steel
Cutting Direction
Right Hand
Insert Shape
120 Degrees Hexagon
Rake
-6.6 Degrees Radial, -7 Degrees Axial
Max. Speed
6,300 RPM
Features
Higher AP1 Max with Standard Insert, Twelve Cutting Edges
ANSI Code
M1200HD400Z06S150HN07
Compatible Hardware
Anti-Seize Lubricant, Coolant Screw Assembly, Insert Screw M4x0.7 x 10 T15, Torx Driver
Insert Style
HNGJ ANENLD
Number of Inserts
6
Insert Holding Type
Screw
Coolant Fed
Coolant Through
ISO Number
M1200HD400Z06S150HN07
Cutting Application
Face Milling, Side and Face Milling, Side/Shoulder Milling: Eased Chamfer
Description
Indexable Profiling End Mill, Max. Cutting Dia. 108.36mm, Depth of Cut 4.70mm, Overall Length 44.45mm, ANSI Code M1200HD400Z06S150HN07, Compatible Hardware Anti-Seize Lubricant, Coolant Screw Assembly, Insert Screw M4x0.7 x 10 T15, Torx Driver, Coolant Fed Coolant Through, Cutting Application Face Milling, Side and Face Milling, Side/Shoulder Milling: Eased Chamfer
