Indexable Profiling End Mill, VSM490-10 Series, High Speed Steel, 10.00mm Depth of Cut
Mfr # 6425490
Zoro # G3791074
product price:Â $875.99
/ea
Free Shipping & Returns
Key Features
Series
VSM490-10
Overall Length
50.00mm
Depth of Cut
10.00mm
Material - Machining
High Speed Steel
Cutting Direction
Right Hand
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption
Specifications
Product Information
MFR #
6425490
Zoro #
G3791074
UPC #
4059782476837
Country of Origin
Multiple
Dimensions
Overall Length
50.00mm
Depth of Cut
10.00mm
Insert Size
100408
Arbor Dia.
1"
Hub Outside Dia.
50.00mm
Details
Item
Indexable Profiling End Mill
Series
VSM490-10
Material - Machining
High Speed Steel
Cutting Direction
Right Hand
Insert Shape
90 Degrees Rectangle Mill 4
Rake
-12.7 Degrees Radial, -8 Degrees Axial
Cutting Application
Face Milling, Side/Shoulder Milling: Square End, Slotting: Square End
Number of Inserts
6
Features
Best-in-Class Wall Finish at Axial Stepping Down Jobs, Coarse, Lower Cutting Forces and Real Soft Cutting Action, Medium and Fine Pitch Cutter Density Available, Perfect Fit for Taper 40 Spindles and Driven Units, True 90 Degrees Roughing Tool with Imbedded Finishing Capability in One
ISO Number
VSM490D080Z06S254XN10JIS
Side Cutting Edge Angle
90 Degrees
Coolant Fed
Coolant Through
Compatible Hardware
Anti-Seize Lubricant, Hardware Chave Torx DT-9IP, Insert Screw M3x0.5 x 7.2 Ip9, SHCS M12 1.75P x 30, SHCS with Coolant Groove
ANSI Code
VSM490D080Z06S254XN10JIS
Insert Style
XNGU SRMM
Max. Speed
17,100 RPM
Insert Holding Type
Screw
Description
Indexable Profiling End Mill, Depth of Cut 10.00mm, Overall Length 50.00mm, ANSI Code VSM490D080Z06S254XN10JIS, Compatible Hardware Anti-Seize Lubricant, Hardware Chave Torx DT-9IP, Insert Screw M3x0.5 x 7.2 Ip9, SHCS M12 1.75P x 30, SHCS with Coolant Groove, Coolant Fed Coolant Through, Cutting Application Face Milling, Side/Shoulder Milling: Square End, Slotting: Square End
