  9. Milling Insert, Parallelogram, 7.00mm
Widia Milling Insert, Parallelogram, 7.00mm BDMT070302ERMS - main

Milling Insert, Parallelogram, 7.00mm

  • Mfr # BDMT070302ERMS

  • Zoro # G3790569

product price: $14.49
/ea
Sold in multiples of 10 for $144.90

Key Features

Grade
TN6430
Insert Style
BDMT
Cutting Direction
Right Hand
Insert Shape
Parallelogram
Series
M6800
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
BDMT070302ERMS
Zoro #
G3790569
UPC #
4021169757761
Country of Origin
Japan

Dimensions

Mounting Hole Dia.
2.31mm
Insert Size
070302
Insert Thickness
0.1024"
Through Hole Inside Dia.
2.31mm
Thickness
0.1024 in
Cutting Edge Length
7.00mm
Corner Radius
0.20mm
Width
4.54mm

Details

Grade
TN6430
Insert Style
BDMT
Cutting Direction
Right Hand
Item
Parallelogram Milling Insert
Insert Shape
Parallelogram
Series
M6800
Mounting Style
Taper Screw
Lead Angle
75 Degrees
For Use With
M6800 Series 90 Degrees Shoulder Mills
Chip-Breaker
Yes
ISO Number
BDMT070302ERMS
Insert Material
Carbide
Clearance Angle
15 Degrees
Primary Material Application
Steel
Number of Cutting Edges
2
Shape
Parallelogram
Measurement System
Metric
Primary Material Application ISO Code
P
Finish - Machining
TiAlN
Included Angle
80 Degrees
Secondary Material Application ISO Code
K
Manufacturer Grade
TN6430
Chip-Breaker Code
MS
Secondary Material Application
Cast Iron
Hole Type
40 Degrees to 60 Degrees Countersink Hole
Chip-Breaker Style
On One Side
Insert Holding Type
Taper Screw
ANSI Code
BDMT070302ERMS
Material - Machining
Carbide
For Toolholder
15396440800, 15396441000, 15396441800, 15396442200, 15396442400, 15396442800, 15396443200, 15396443400, 15396445000, 15396446200, 15396447200

Description

Parallelogram Milling Insert, BDMT070302ERMS, MS, On One Side, 15 Degrees
