Thread Turning Toolholder, E20SSDQCL11
Mfr # E20SSDQCL11
Zoro # G3821299
product price: $921.99
/ea
Free Shipping & Returns
Key Features
Insert Size
11T308
Cutting Direction
Left Hand
ISO Number
E20SSDQCL11
Rake
-7 Degrees Radial, 0 Degrees Axial
Shank Dia.
20.00mm
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
E20SSDQCL11
Zoro #
G3821299
UPC #
4021169123924
Country of Origin
Germany
Dimensions
Insert Size
11T308
Shank Dia.
20.00mm
Cutting Dia.
0.7874mm
Overall Length
250.00mm
Min. Bore Dia.
25.00mm
Insert Cutting Edge Length
11.63mm
Details
Item
Indexable Thread Turning Tool Holder
Cutting Direction
Left Hand
ISO Number
E20SSDQCL11
Rake
-7 Degrees Radial, 0 Degrees Axial
Shank Shape
Offset
Shank Material
Carbide
ANSI Code
E20SSDQCL11
Toolholder Style
E-SDQC
Insert Style
DC..
Insert Holding Type
Screw Clamping
Center to Cutting Tip
0 in
Number of Coolant Holes
1
Coolant Fed
Coolant Through
Cutting Application
Inside Diameter Chamfering, Inside Diameter Chamfering and Profiling
Measurement System
Metric
Description
Indexable Thread Turning Tool Holder, Insert Style DC.., Left Hand, Inside Diameter Chamfering, Inside Diameter Chamfering and Profiling, ANSI Code E20SSDQCL11, Center to Cutting Tip 0 in, Coolant Fed Coolant Through
