Backflow Preventer, 2 in. Size, Bronze

  • Mfr # 2-375XLB

  • Zoro # G2373449

product price:
$
1,870.99
/ea
Free Shipping & Returns

Key Features

Body Material
Low Lead Cast Bronze
Temp. Range
33 Degrees to 180 Degrees F
Width
9 1/2 in
Pipe Size
2"
Series
Wilkins 375XLB
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
2-375XLB
Zoro #
G2373449
UPC #
612052208183
Country of Origin
United States

Dimensions

Width
9 1/2 in
Pipe Size
2"
Length
16 in
Size
2 in
Height
9 1/2 in
Overall Height
9.5 in
Connection Size - Side 2
2 in
Connection Size - Side 1
2 in
Overall Length
16 in
Nominal Valve Size
2 in
Overall Width
9.5 in
Wire Rope Length
16 in

Details

Item
Reduced Pressure Zone Backflow Preventer
Body Material
Low Lead Cast Bronze
Temp. Range
33 Degrees to 180 Degrees F
Series
Wilkins 375XLB
Connection
FNPT
Compliance
AWWA Compliant C511, CSA Certified B64.4, NSF/ANSI 375 By IAPMO R and T
Max. Pressure
175 psi
Max. Temp.
180 Degrees F
Standards
Annex G, Approved by the Foundation for Cross-Connection Control and Hydraulic Research at the University of Southern California, ASSE 1013, AWWA C511, C-UL Classified, CSA B64.4, IAPMO Listed, NSF Listed-Standard 61, NSF/ANSI 61, UL Listed
Features
Black UV Stabilized Fusion Epoxy Coating to Help Deter Theft
Flow
245 gpm
Spring Material
Stainless Steel
Maximum Pressure - Operating
175 psi
Connection Gender - Side 2
Female
Connection Type - Side 2
NPTF
Includes Strainer
No Strainer
Includes Freeze Sensor
No Freeze Sensor
Shut-Off Valve Included
Ball Valve
Backflow Preventer Type
Reduced Pressure Assembly (RP)
Hazard Protection Level
High Hazard
Operating Temperature - Maximum
180 Degrees F
Operating Temperature - Minimum
33 Degrees F
Mounting Orientation
Horizontal
Connection Gender - Side 1
Female
For Media
Water
Connection Type - Side 1
NPTF
Valve Series
375XLB

Description

Backflow Preventer,2 in. Size,Bronze

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
