  5. Low Pressure Gauge, 0 to 32 psi, 2 1/2 in Dial, 1/4 in NPT, Bottom Location, Steel Case Material
Winters Low Pressure Gauge, 0 to 32 psi, 2 1/2 in Dial, 1/4 in NPT, Bottom Location, Steel Case Material PLP301 - main

Low Pressure Gauge, 0 to 32 psi, 2 1/2 in Dial, 1/4 in NPT, Bottom Location, Steel Case Material

  • Mfr # PLP301

  • Zoro # G3807925

product price:  $38.99
/ea

Key Features

Accuracy
+/-3-2-3%
Process Connection Location
Bottom
Process Connection Size
1/4 in
Process Connection Type
NPT
Dial Size (In.)
2 1/2 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
PLP301
Zoro #
G3807925
UPC #
628311203165
Country of Origin
Taiwan, Province of China

Dimensions

Process Connection Size
1/4 in
Dial Size (In.)
2 1/2 in
Length
3.450"
Manufacturer Warranty Length
5 yr
Nominal Dial Size
2 1/2 in
Case Depth
1.9 in
Case Diameter
2.625 in
Nominal Dial Diameter
2 1/2 in

Details

Item
Low Pressure Gauge
Accuracy
+/-3-2-3%
Process Connection Location
Bottom
Process Connection Type
NPT
Application
Air Compressors, Air Filters, Regulators and Respirators, Vacuum Applications
Gauge Case Material
Steel
Series
PLP
Lens Material
Polycarbonate
Primary Pressure Range
0 to 32
Primary Scale Units
in wc
IP/NEMA Rating
IP52
Liquid-Filled Case
No
Hazardous Location Rating
Not Rated
Panel-Mountable
No
Case Color
Black
Gauge Application
For Natural Gas & Other Gases
Characteristics
Suitable for Corrosive and Non Corrosive Gaseous Media, Natural Gas and Propane Pressure, Air Flow Indication, Leak Detection
For Use With
Air Compressors, Air Filters, Gas Burners, Respirators, Suction Regulators, Vacuum Ovens, Vacuum Pumps
Graduations
0.5 in wc, 0.5 oz/sq in
Calibration Certificate Included
No
Socket Material
Brass
Case Material
Steel
Standards
CRN
Wetted Materials
Brass / Bronze
Connection Type
MNPT
Pressure Range Type
Pressure
Compatible Process Media
Gaseous
Process Connection Gender
Male
Removable Bezel
No
Process Temperature Range
-40 Degrees to 150 Degrees F
Dial Color
White
Field Fillable
No
Includes Mounting Hardware
No
Accuracy Scale
Mid-Scale
Over-Pressure Limit
30% of Full Scale
Sensor Material
Bronze
Accuracy Grade
ASME B40.100 Grade B
Includes Calibration Certificate
No
Includes Vent Plug
No
Dry Dampening Feature
None
Bezel Mounting Type
No Bezel
Ambient Operating Temperature Range
-40 Degrees to 150 Degrees F, -40 Degrees to 65 Degrees C
Scale Type
Dual
Dial Face Material
Aluminum
Cleaned for Oxygen Service
No
Pressure Gauge Type
Low Pressure Gauge
Gauge Case Liquid
None
Pointer Characteristics
Aluminum, Anodized Black
Pointer Material
Aluminum
Pointer Color
Black
Vibration Resistance
None
Freeze Resistant Movement
No
Sensor Type
Diaphragm
Adjustable Pointer
No
Case Finish
Painted
Operating Temperature Range
-40 Degrees to 150 Degrees F
Secondary Scale Pressure Measurement - Minimum
0 oz/sq in
Process Media Temperature - Minimum
-40 Degrees F
Compatible with Brand
Universal
Primary Scale Pressure Measurement - Minimum
0 in wc
Operating Temperature - Minimum
-40 Degrees F
IP Rating
IP52
Case Liquid
None
Operating Temperature - Maximum
150 Degrees F
Process Media Temperature - Maximum
150 Degrees F
Secondary Scale Pressure Measurement - Maximum
18.5 oz/sq in
NEMA Enclosure Rating
5
Primary Scale Pressure Measurement - Maximum
32 in wc

Description

Low Pressure Gauge, Nominal Dial Size 2 1/2 in, Accuracy +/-3-2-3 Percent, Gauge Case Material Steel, Process Connection Type NPT, Process Connection Gender Male, Lens Material Polycarbonate, Process Connection Size 1/4 in, Field Fillable No, Process Connection Location Bottom, Case Color Black, IP/NEMA Rating IP52, Primary Pressure Range 0 to 32, Dry Dampening Feature None, Vibration Resistance None, Dial Color White, Pressure Gauge Type Low Pressure Gauge, Liquid-Filled Case No
