  5. Panel-Mount Vacuum Gauge, 30 to 0 psi, 2 in Dial, 1/4 in NPT, Center Back Location
Winters Panel-Mount Vacuum Gauge, 30 to 0 psi, 2 in Dial, 1/4 in NPT, Center Back Location P9U901428UC - main

Panel-Mount Vacuum Gauge, 30 to 0 psi, 2 in Dial, 1/4 in NPT, Center Back Location

  • Mfr # P9U901428UC

  • Zoro # G1615282

product price:  $11.89
/ea

Key Features

Accuracy
+/-2-1-2%
Process Connection Location
Center Back
Process Connection Size
1/4 in
Process Connection Type
NPT
Dial Size (In.)
2 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
P9U901428UC
Zoro #
G1615282
UPC #
628311209204
Country of Origin
China

Dimensions

Process Connection Size
1/4 in
Dial Size (In.)
2 in
Nominal Dial Size
2 in
Case Diameter
2.271 in
Manufacturer Warranty Length
5 yr
For Panel Cut-Out Size
2.11 in
Case Depth
1.145 in
Nominal Dial Diameter
2 in

Details

Item
Panel-Mount Vacuum Gauge
Accuracy
+/-2-1-2%
Process Connection Location
Center Back
Process Connection Type
NPT
Application
Compressors, Panels, Water Pressure Testing, Severe Ambient Conditions
Gauge Case Material
Steel
Series
P9U 90
Lens Material
Acrylic
Primary Pressure Range
30 to 0
Primary Scale Units
in Hg
IP/NEMA Rating
IP52
Liquid-Filled Case
No
Hazardous Location Rating
Not Rated
Panel-Mountable
Yes
Blowout Safety Back
No
Gauge Secondary Range Values
-100 to 0
Calibration Certificate Included
No
For Use With
Media Compatible with Bronze
Socket Material
Brass
Case Color
Black
Gauge Primary Range Numbered Graduations
5/20
Gauge Special Options
Zero Adjustment Screw
Gauge Application
U-Clamp
Case Material
Steel
Gauge Primary Range Smallest Graduation
1/10
Smallest Graduation
0.5 in Hg/ 2kPa
Connection Type
MNPT
Standards
ANSI/ASME, ASME, CRN
Gauge Case Liquid
None
Vibration Resistance
Dry Case Vibration-Dampened
Case Construction
Welded Joint
Includes Mounting Hardware
Yes
Non-Sparking
No
Over-Pressure Limit
25%
Dial Color
White
Includes Calibration Certificate
No
Pressure Gauge Type
Process Pressure Gauge
Pointer Material
Aluminum
Removable Bezel
No
Dry Dampening Feature
Flutterless Pointer with Dampened Movement
Sensor Material
Bronze
Scale Type
Dual
Process Connection Gender
Male
Cleaned for Oxygen Service
No
Compatible Process Media
Non-Clogging, Non-Corroding
Pointer Color
Black
Field Fillable
No
Ambient Operating Temperature Range
-40 Degrees to 150 Degrees F
Movement Material
Brass
Process Temperature Range
-40 Degrees to 150 Degrees F
Freeze Resistant Movement
No
Secondary Scale Units
kPa
Dial Face Material
Aluminum
Secondary Pressure Range
-101 to 0
Case Finish
Painted
Accuracy Grade
ASME B40.100 Grade A
Pressure Range Type
Vacuum
Includes Vent Plug
No
Sensor Type
Bourdon Tube
Mounting Hardware Included
Yes
Accuracy Scale
Mid-Scale
Operating Temperature Range
-40 Degrees to 150 Degrees F
Secondary Scale Pressure Measurement - Minimum
0 kPa
Primary Scale Vacuum Measurement - Maximum
30 in Hg
Operating Temperature - Maximum
150 Degrees F
Process Media Temperature - Minimum
-40 Degrees F
Primary Scale Vacuum Measurement - Minimum
0 in Hg
Secondary Scale Vacuum Measurement - Maximum
0 kPa
Case Liquid
None
Secondary Scale Vacuum Measurement - Minimum
-101 kPa
Process Media Temperature - Maximum
150 Degrees F
Primary Scale Pressure Measurement - Maximum
-30 in Hg
NEMA Enclosure Rating
5
Secondary Scale Pressure Measurement - Maximum
-100 kPa
Compatible with Brand
Universal
IP Rating
IP52
Operating Temperature - Minimum
-40 Degrees F
Primary Scale Pressure Measurement - Minimum
0 in Hg

Description

Panel-Mount Vacuum Gauge, Nominal Dial Size 2 in, Accuracy +/-2-1-2 Percent, Gauge Case Material Steel, Process Connection Type NPT, Process Connection Gender Male, Lens Material Acrylic, Process Connection Size 1/4 in, Field Fillable No, For Panel Cut-Out Size 2.11 in, Process Connection Location Center Back, Case Color Black, IP/NEMA Rating IP52, Primary Pressure Range 30 to 0, Dry Dampening Feature Flutterless Pointer with Dampened Movement, Vibration Resistance Dry Case Vibration-Dampened
