  5. Pressure Gauge, 0 to 200 psi psi, 4 1/2 in Dial, 1/4 in NPT Bottom Location
Winters Pressure Gauge, 0 to 200 psi psi, 4 1/2 in Dial, 1/4 in NPT Bottom Location PCT325LF - main

Pressure Gauge, 0 to 200 psi psi, 4 1/2 in Dial, 1/4 in NPT Bottom Location

  • Mfr # PCT325LF

  • Zoro # G6176581

product price:  $30.19
/ea

Key Features

Accuracy
+/-1.0%
Process Connection Location
Bottom
Process Connection Size
1/4 in NPT
Dial Size (In.)
4 1/2 in
Gauge Case Material
304 Stainless Steel
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
PCT325LF
Zoro #
G6176581
UPC #
628311250121
Country of Origin
China

Dimensions

Process Connection Size
1/4 in NPT
Dial Size (In.)
4 1/2 in
Nominal Dial Size
4 1/2 in
Case Diameter
5.9 in
Manufacturer Warranty Length
5 yr

Details

Item
Pressure Gauge
Accuracy
+/-1.0%
Process Connection Location
Bottom
Gauge Case Material
304 Stainless Steel
Series
PCT-LF
Lens Material
Acrylic
Primary Pressure Range
0 to 200 psi
Primary Scale Units
psi
Liquid-Filled Case
No
Panel-Mountable
No
Calibration Certificate Included
No
For Use With
Most Commercial Air, Water, and Steam Services That Require A 1% Full-Scale Accuracy
Case Color
Silver
Characteristics
CRN Registered, Zero Adjustment Screw
Gauge Application
Most Commercial Air, Water and Steam Services (with Syphon)
Gauge Special Options
Zero Adjustment Screw
Socket Material
Brass
Pressure Range
0 to 200 psi/kPa
Case Material
304 Stainless Steel
NSF Certified
Yes
Standards
CRN Registered
Wetted Materials
Brass / Bronze
Connection Type
MNPT
Pressure Range Type
Pressure Gauge
Sensor Material
Bronze
Maximum Pressure
200
Operating Temperature Range
-40 Degrees to 200 Degrees F

Description

Pressure Gauge, Accuracy +/-1.0 Percent, Gauge Case Material 304 Stainless Steel, Lens Material Acrylic, Socket Material Brass
