1/2" MNPT Brass Piston Spring Check Valve

  • Mfr # CHK BRS 810-8M8M-B

  • Zoro # G1516076

product price:
$
30.29
/ea

Key Features

Pipe Size
1/2"
Hex Size
7/8 in
Connection Type
MNPT
Connection
MNPT
Body Material
Brass
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
CHK BRS 810-8M8M-B
Zoro #
G1516076
UPC #
-
Country of Origin
United States

Dimensions

Pipe Size
1/2"
Hex Size
7/8 in
Overall Height
7/8"
Length
2"
Pipe or Tube Size - Check Valves
1/2 in
Size
1/2"
Width
0.88"
Overall Length
1.88 in
Pipe or Tube Size
1/2 in
Nominal Valve Size
1/2 in
Connection Size - Side 2
1/2 in
Connection Size - Side 1
1/2 in
Height - Cap to Inlet Center
5 7/16 in
Wire Rope Length
1.88 in

Details

Connection Type
MNPT
Connection
MNPT
Body Material
Brass
Max. Steam Pressure - Valves
Not Rated
Mounting Orientation - Check Valves
Horizontal, Vertical
Mechanism and Body Design
Inline Piston
Seat Material
Brass
Spring Material - Check Valves
Stainless Steel
Spring Material
Stainless Steel
Material of Construction
Brass
Application - Valves
General Purpose
Mounting Position
Vertical or Horizontal
Body Material - Valves
Brass
Min. Temp. - Valves
-20 Degrees F
Item - Check Valves
Check Valve
Max. Water Pressure
500 psi
Max. Temp.
250 Degrees F
Connection Type - Check Valves
MNPT x MNPT
Cracking Pressure - Check Valves
1.000 psi
Sub-Category
Brass
Cracking Pressure
1 psi
Seat Material - Check Valves
Brass
Max. Pressure
500 psi
Full Flow - Valves
Yes
Seal Material
Buna-N
Seal Material - Check Valves
Buna-N
Max. Temp. - Valves
180 Degrees F
Item
Piston Spring Check Valve
Max. Water Pressure - Valves
500 psi
Cap to Inlet Center
5 7/16 in
Mounting Orientation
Horizontal, Vertical
Seal
Buna
Type
Piston Design
Connection Type - Side 1
NPT
Operating Temperature - Maximum
180 Degrees F
Connection Gender - Side 1
Male
Connection Type - Side 2
NPT
Connection Gender - Side 2
Male
Vacuum Service Rating
Not Rated
Check Mechanism
Piston
Silent Check
Standard
Maximum Pressure - Steam
Not Rated
Coefficient of Volume (Cv)
2.2
For Media
Air, Fluids
Valve Body Style
Inline
3-A Standard Compliance
Not Rated
Maximum Pressure - Operating
500 psi
Check Mechanism Material
Brass
Operating Temperature - Minimum
-20 Degrees F
Valve Series
810

Description

ZORO SELECT Series 810 check valve is an inline piston spring check valve for use with air and fluid media. It is designed for one-direction flow applications and includes a spring-loaded piston check mechanism. This brass valve features a full-flow design with 1/2 in. MNPT x MNPT connections and can be mounted horizontally or vertically.

Key Features:

  • Inline piston spring check valve with brass body, brass check mechanism, and brass seat
  • 1/2 in. male NPT connections on both ends (MNPT x MNPT)
  • Cracking pressure: 1 psi
  • Media: air and fluids
  • Maximum pressure: 500 psi
  • Temperature range: -20 degrees F to 180 degrees F
  • Seal material: Buna-N
  • Spring material: stainless steel
  • Full-flow design
  • Mounting orientation: horizontal or vertical
  • Valve series: 810
  • Overall length: 1.88 in.
  • Overall height/width: 7/8 in.
