1/2" NPT Stainless Steel Swing Check Valve

product price: $65.99
/ea
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Pipe Size 1/2"
  • Hex Size 1 1/16"
  • Connection Type FNPT x FNPT
  • Connection NPT
  • Body Material 316 Stainless Steel
See all product information

Product Information

Dimensions

Pipe Size 1/2"
Hex Size 1 1/16"
Length 2 9/16 in
Overall Height 2 9/16 in
Size 1/2"
Width 1 53/64 in
Pipe or Tube Size - Check Valves 1/2 in
Pipe or Tube Size 1/2 in

Details

Connection Type FNPT x FNPT
Connection NPT
Body Material 316 Stainless Steel
Material of Construction 316 Stainless Steel
Cracking Pressure 4.27 psi
Max. Steam Pressure - Valves 200 psi WSP
Max. Pressure Water: 200 psi, Steam: 200 psi WSP
Cap to Inlet Center 1 11/16 in
Max. Water Pressure - Valves 200 psi
Max. Water Pressure 200 psi
Flow 6.9 gpm
Sub-Category Stainless Steel
Application - Valves General Purpose
Flow Design Single
Mechanism and Body Design Inline Swing
Item - Check Valves Check Valve
Connection Type - Check Valves FNPT x FNPT
Min. Temp. - Valves -4 Degrees F
Seal Material - Check Valves PTFE
Max. Temp. - Valves 350 Degrees F
Mounting Position Horizontal
Item Swing Check Valve
Cracking Pressure - Check Valves 0.5 psi
Max. Temp. 353 Degrees F
Full Flow - Valves Yes
Body Material - Valves 316 Stainless Steel
Mounting Orientation - Check Valves Horizontal
Flow - Valves 6.9 gpm
Seal Material PTFE
Mounting Orientation Horizontal
Seal NBR Rubber SN-919F

Description

Item - Check Valves Check Valve, Flow Design Single, Mechanism and Body Design Inline Swing, Body Material - Valves 316 Stainless Steel, Pipe or Tube Size 1/2 in, Connection Type FNPT x FNPT, Cracking Pressure 0.5 psi, Mounting Orientation Horizontal, Seal Material PTFE, Max. Temp. - Valves 350 Degrees F, Min. Temp. - Valves -4 Degrees F, Max. Water Pressure - Valves 200 psi, Max. Steam Pressure - Valves 200 psi WSP, Flow - Valves 6.9 gpm, Full Flow - Valves Yes
