Zoro Select 2" Sweat Brass Ball Valve Inline 107-848NL - main

2" Sweat Brass Ball Valve Inline

  • Mfr # 107-848NL

  • Zoro # G4975424

product price: $94.35
/ea
Free Shipping & Returns

Key Features

Ball Material
304 Stainless Steel
Body Style
Inline
Ball Port Style
Full Port
Valve Ways
2-Way
Valve Structure
Two-Piece
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
107-848NL
Zoro #
G4975424
UPC #
-
Country of Origin
China

Dimensions

Pipe Size
2 in
Overall Length
8.39 in
Connection Size - Side 1
2 in
Nominal Valve Size
2 in
Connection Size - Side 2
2 in

Details

Ball Material
304 Stainless Steel
Body Style
Inline
Ball Port Style
Full Port
Valve Ways
2-Way
Valve Structure
Two-Piece
For Media
Combustible Gases, Steam, Water
Connection Type
Sweat x Sweat
Item
Ball Valve
Stem Type
Blowout Proof
Temp. Range
0 Degrees F to 365 Degrees F
Handle Type
Lever
Ball Valve Product Group
Manual
Seat Material
PTFE
Stem Material
Brass
Body Material
Brass
Handle Material
Steel
Max. Pressure
600 PSI CWP
Standards
AB 1953, ANSI Z1157-2014e1, FM 1140, IAMPO IGC 157, NSF/ANSI 14, NSF/ANSI 372, NSF/ANSI 61
Seal Material
PTFE
Type
Two Piece
Vented Ball Valve
Non-Vented
Color - Valve Handle
Yellow
3-A Standard Compliance
Not Rated
Operating Temperature - Maximum
300 Degrees F
Handle - Locking
Non-Locking
Maximum Pressure - Steam
150 PSI WSP
Maximum Pressure - Combustible Gas
Not Rated
Coefficient of Volume (Cv)
144.194
Operating Temperature - Minimum
-20 Degrees F
Connection Type - Side 2
Sweat
Connection Type - Side 1
Sweat
Vacuum Service Rating
-29.92 in Hg
NSF Certifications for Food and Drinking Water
NSF 61
Valve Series
7700S

Description

Manual Two-Way Ball Valve, Body Material Brass, For Media Combustible Gases, Steam, Water, Valve Construction Two-Piece, Nominal Valve Size 2 in, Valve Body Style Straight, 3-A Standard Compliance Not Rated, Average Surface Roughness (Ra) Not Applicable, Maximum Pressure - Operating 600 psi, Maximum Pressure - Steam 600 psi, Maximum Pressure - Combustible Gas Not Rated, Vacuum Service Rating -29.92 in Hg, Ball Material 304 Stainless Steel, Ball Port Style Full Port, Handle - Locking Non-Locking
