  11. NEMA 20A 4-3/16" H x 1-3/4" W x 1-1/8" D Power Inlet
Zoro Select NEMA 20A 4-3/16" H x 1-3/4" W x 1-1/8" D Power Inlet 2097TRNICC4 - main

NEMA 20A 4-3/16" H x 1-3/4" W x 1-1/8" D Power Inlet

  • Mfr # 2097TRNICC4

  • Zoro # G8035947

product price: $41.29
/ea

Key Features

Current Rating
20 A
GFCI
Yes
Housing Material
Thermoplastic
Mounting Type
Box
NEMA Receptacle Configuration
5-20R
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
2097TRNICC4
Zoro #
G8035947
UPC #
-
Country of Origin
China

Dimensions

Height
4-3/16"
Depth
1-1/8"
Width
1-3/4"
Face Plate Height
2.7 in
Minimum Wire Size
14 AWG
Face Plate Width
1.7 in
Maximum Wire Size
10 AWG
Overall Depth
1 in

Details

Item
Power Inlet
Current Rating
20 A
GFCI
Yes
Housing Color
Nickel
Housing Material
Thermoplastic
Mounting Type
Box
NEMA Receptacle Configuration
5-20R
Number of Poles
2
Number of Wires
3
Standards
cULus Listed, FSUL, UL Listed
Voltage Rating
125V AC
Amps
20
Reset Type
Automatic
Receptacle Type
GFCI
Indoor/Outdoor
Indoor
Voltage
125VAC
Number of Outlets
2
Color
Nickel
UL 94 Flammability Rating
V-2
Wire Connection Type
Screw Terminals
Minimum Operating Temperature
-31 Degrees F
Number of Gangs
1
Self Testing
Yes
Maximum Operating Temperature
150.8 Degrees F
Market
Industrial
Number of Wall Plates Included
2
For Location
Outdoor
Contact Material
Brass
Grade
Federal Specification
Includes Mounting Hardware
Yes
Resistance Properties
Tamper Resistant
For Environment
Institutional
Maximum Surge Current
6 mA
Compatible with Series
Radiant(R)
IEC Configuration
309
Hub Type
Feed Through
Environmental Conditions
95% Humidity, UL 94 V2
Finish
Frosted
Special Features
Spec Grade
NEMA Configuration Code
5-20R
NEMA Rating
20A
Number of Receptacles
2
Amperage
20.0 A
Outlet Type
Tamper-Resistant,Self-Test,GFCI,Indoor

Description

Power Inlet, Cover Type No Cover, Current Rating 20 A, GFCI Yes, Grounding Grounded, Hazardous Location Specification Not Applicable, Housing Color Nickel, Housing Material Plastic, Mount Type Flush, NEMA Enclosure Rating 5, NEMA Receptacle Configuration 5-20R, Number of Gangs 1, Number of Poles 2, Number of Wires 3, Phase Single, Polarized No, Receptacle Type Duplex, Resistance Properties Tamper Resistant, Standards cULus Listed, FSUL, UL Listed, Voltage Rating 125V AC
