Zoro Select Plate Caster, 5" Wheel Dia., 220 lb., Gray 435X69 - main

Plate Caster, 5" Wheel Dia., 220 lb., Gray

  • Mfr # 435X69

  • Zoro # G6049467

product price:  $7.65
/ea

Key Features

Caster Frame Material
Steel
Wheel Dia.
5 in
Number of Wheels
1
Mounting Bolt Dia.
5/16 in
Load Rating
220 lb
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
435X69
Zoro #
G6049467
UPC #
-
Country of Origin
China

Dimensions

Wheel Dia.
5 in
Mounting Bolt Dia.
5/16 in
Overall Height
5-5/8in
Wheel Width
1 1/4 in
Mounting Plate Size
2 3/8 in x 3 5/8 in
Mounting Height
5 5/8 in
Mounting Plate Thickness
3/32in

Details

Caster Frame Material
Steel
Number of Wheels
1
Load Rating
220 lb
Extended Lead
No
Caster Brake Included
No
Frame Finish
Zinc Plated
Caster Sub-Type
Rigid
Standards
ISO 9001
Wheel Color
Blue
Caster Plate Hole Pattern
D
Core Color
Gray
Outside Bolt Hole Spacing
1-3/4 in x 3 in
Application
General Purpose
Non-Marking
Yes
Inside Bolt Hole Spacing
1-3/4 in x 3 in
Caster Temp. Range Available
No
Item
Plate Caster
Thread Guards
No
Load Rating Range
0 to 299 lb
Swivel Construction
Kingpinless
Includes Thread Guards
No
Swivel Lock Type
No Lock Included
Number of Mounting Holes
4
Tread Shape
Standard
Wheel/Tread Hardness Rating
Firm
Caster Brake Type
No Brake
Wheel Bearing Type
Delrin
Wheel Core Material
Polyolefin
Wheel/Tread Material
Polyurethane
Wheel/Tread Color
Blue
System of Measurement
Inch
Wheel Hardness Rating
95 Shore A
Load Capacity - Maximum
220 lb
Operating Temperature - Maximum
175 Degrees F
Operating Temperature - Minimum
-40 Degrees F

Description

Rigid, Plate Caster, Load Rating 220 lb, Swivel Lock Type No Lock Included, Wheel Dia. 5 in, Wheel Width 1 1/4 in, Wheel/Tread Material Polyurethane, Wheel Core Material Polyolefin, Non-Marking Yes, Number of Wheels 1, Caster Brake Type No Brake, Tread Shape Standard
