Shop ZORO SELECT

Rigid Plate Shock-Absorbing Castr, 550 lb

  • Mfr # GDS-200A-RF
  • Zoro # G0490122
product price:
$
183.99
/ea
Free Shipping & Returns

Key Features

Outside Bolt Hole Spacing
2-3/4 in x 2-3/4 in
Non-Marking
Yes
Number of Wheels
1
Caster Sub-Type
Rigid
Caster Frame Material
Aluminum
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
GDS-200A-RF
Zoro #
G0490122
UPC #
-
Country of Origin
United States

Dimensions

Overall Height
10-5/8"
Mounting Bolt Dia.
3/8 in
Wheel Dia.
8 in
Wheel Width
1 5/8 in
Mounting Height
10 3/4 in
Mounting Plate Size
3 3/4 in x 3 3/4 in
Mounting Plate Thickness
6 1/2 mm
Mounting Plate Length
95 mm
Bolt Hole Spacing - Length
10 mm
Bolt Hole Spacing - Width
11 mm
Overall Wheel Width
8 in
Mounting Plate Width
95 mm

Details

Outside Bolt Hole Spacing
2-3/4 in x 2-3/4 in
Non-Marking
Yes
Number of Wheels
1
Caster Sub-Type
Rigid
Caster Frame Material
Aluminum
Wheel Color
Clear
Caster Temp. Range Available
Yes
Load Rating
550 lb
Item
Plate Caster
Features
Shock Absorbing
Caster Plate Hole Pattern
D
Inside Bolt Hole Spacing
2-3/4 in x 2-3/4 in
Caster Brake Included
No
Includes
Mounting Hardware
Core Color
Gray
Standards
ANSI, CE
Frame Finish
Powder Coated
Swivel Construction
Kingpinless
Caster Brake Type
No Brake
Swivel Raceway Type
Double Ball
Includes Thread Guards
Yes
Wheel/Tread Hardness Rating
Firm
Wheel Core Material
Aluminum
Tread Shape
Donut
Wheel Bearing Type
Ball
Load Rating Range
300 to 999 lb
Swivel Lock Type
No Lock Included
Number of Mounting Holes
4
Wheel/Tread Material
Polyurethane
Wheel/Tread Color
Clear
Wheel Type
Solid
Wheel Hardness Rating
90 Shore A
Load Capacity - Maximum
550 lb
Mounting Hole Type
Hole
For Surface Type
Asphalt, Ceramic, Rubber, Tile, Vinyl, Wood
Caster Features
Shock-Absorbing
Mounting Plate Shape
Rectangle
Wheel Bearing Material
Steel
Wheel Core Type
Solid
Brake Location
Face
Operating Temperature - Minimum
15 Degrees F
Operating Temperature - Maximum
190 Degrees F
Operating Temperature Range
14 Degrees to 194 Degrees F

Description

Rigid, Plate Caster, Load Rating 550 lb, Swivel Lock Type No Lock Included, Wheel Dia. 8 in, Wheel Width 1 5/8 in, Wheel/Tread Material Polyurethane, Wheel Core Material Aluminum, Non-Marking Yes, Number of Wheels 1, Caster Brake Type No Brake, Tread Shape Donut
