Shop ZORO SELECT

Swivl Sld Rubr Whl Cstr, 10-1/4 in, 440 lb

  • Mfr # L-VW 260K
  • Zoro # G4623814
product price:
$
306.99
/ea
Free Shipping & Returns

Key Features

Frame Finish
Zinc Plated
Caster Stem Type
No Stem/Plate Included
Outside Bolt Hole Spacing
5-1/2 in x 5-1/2 in
Load Rating
440 lb
Caster Sub-Type
Swivel
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
L-VW 260K
Zoro #
G4623814
UPC #
-
Country of Origin
Germany

Dimensions

Stem Dia.
No Stem
Wheel Width
3 3/8 in
Mounting Bolt Dia.
9/16 in
Wheel Dia.
10 1/4 in
Overall Height
12-1/8"
Mounting Height
12 1/8 in
Mounting Plate Size
175 mm x 175 mm
Swivel Radius
208 mm
Bolt Hole Spacing - Length
5.5 in
Overall Wheel Width
3 3/8 in
Mounting Plate Thickness
5/32 in
For Axle Dia.
12 mm
Mounting Plate Length
6 7/8 in
Bolt Hole Spacing - Width
5.5 in

Details

Frame Finish
Zinc Plated
Caster Stem Type
No Stem/Plate Included
Outside Bolt Hole Spacing
5-1/2 in x 5-1/2 in
Load Rating
440 lb
Caster Sub-Type
Swivel
Caster Temp. Range Available
No
Tread
Smooth
Number of Wheels
1
Item
Plate Caster
Hub Color
Gray
Caster Brake Included
Yes
Inside Bolt Hole Spacing
5-1/2 in x 5-1/2 in
Caster Plate Hole Pattern
D
Application
Retail, Industrial, Commercial
Includes
Top Grease Seal
Tread Color
Black
System of Measurement
Metric
Caster Brake Type
No Brake
Core Color
Gray
Non-Marking
No
Caster Mounting Type
Plate
Replacement Wheel
VW 260/20K
Standards
DIN EN 12532, ISO 9001
Wheel/Tread Material
Rubber
Number of Mounting Holes
4
Wheel/Tread Hardness Rating
Soft
Swivel Raceway Type
Double Ball
Caster Frame Material
Steel
Swivel Construction
Kingpin
Wheel Bearing Type
Ball
Includes Thread Guards
No
Load Rating Range
Light-Medium Duty
Wheel Type
Flat-Free
Extended Lead
No
Wheel Core Material
Pressed Steel
Resistant To
Chemical Resistance To Many Aggressive Substances, Except Oils
ESD Conductive
No
Series
L Series
Tread Shape
Standard
Load Capacity
200 kg
Wheel Hardness Rating
50 Shore A
Load Capacity - Maximum
440 lb
Mounting Plate Shape
Square
Wheel Bearing Material
Steel
Caster Features
Corrosion-Resistant
Wheel Core Type
Solid
Mounting Hole Type
Hole
For Surface Type
Asphalt, Ceramic, Grease, Rubber, Steel
Operating Temperature Range
-25 Degrees To 80 Degrees C

Description

Swivel, Plate Caster, Load Rating 440 lb, Wheel Dia. 10 1/4 in, Wheel Width 3 3/8 in, Wheel/Tread Material Rubber, Non-Marking No, Number of Wheels 1, Caster Brake Type No Brake, Tread Shape Standard
