  11. Water Pressure Reducing Valve, 2 In.
Apollo Valves Water Pressure Reducing Valve, 2 In. 36LF40801 - main

Water Pressure Reducing Valve, 2 In.

  • Mfr # 36LF40801

  • Zoro # G5274674

product price: $590.99
/ea
Free Shipping & Returns

Key Features

Pipe Size
2"
Connection Type
Double Union NPT
Body Material
Lead Free Bronze
Max. Pressure
300 psig
Max. Temp.
180 Degrees F
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
36LF40801
Zoro #
G5274674
UPC #
670750651311
Country of Origin
United States

Dimensions

Pipe Size
2"
Length
9 57/64 in
Height
11 1/2 in
Overall Height
5 5/8 in
Inlet Connection Size
2 in
Overall Width
9 13/16 in
Outlet Connection Size
2 in

Details

Connection Type
Double Union NPT
Body Material
Lead Free Bronze
Max. Pressure
300 psig
Max. Temp.
180 Degrees F
Item
Water Pressure Reducing Valve
Preset Pressure Settings
50 psi
Valve Type
Standard
Pressure Adjustment Range
5 to 75 psig
Material
Lead Free Bronze
Application
Residential and Commercial
Strainer
No
Standards
ASSE 1003, CSA B356, NSF 372,ARRA
Connection
Double Union FNPT
Material of Construction
Lead Free Bronze
Factory Set Pressure
50 psi
Seat Material
EPDM
Disc Material
EPDM
Pilot Adjustment - Minimum
25 psig
Flow Rate - Continuous Maximum
127 gpm
Inlet Connection Type
NPT
Bonnet Material
Bronze
Operating Pressure - Minimum
25 psi
NSF Certifications for Food and Drinking Water
NSF 372
Coating/Lining
NSF Listed Fusion Bonded Epoxy Lining and Coating
Pilot Adjustment - Maximum
75 psig
Includes Strainer
Strainer Included
Fluid Temperature - Maximum
180 Degrees F
Outlet Connection Type
NPT
Operating Pressure - Maximum
300 psi
For Media
Water

Description

Valve, Pressure Reducing, Material of Construction Lead Free Bronze, Inlet/Outlet 2 In., Double Union NPT Connection, Max. Working Pressure (PSI) 300, Adjustable Range 25-75 psi, Pressure Setting 50 psi, Max. Temp. (F) 180, Height (In.) 11-1/2, Length (In.) 9-8/9, Certification CA AB1953, VT ACT 193, Standards ASSE 1003/CSA B356, Compliance ARRA

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
