Shop A.R. NORTH AMERICA

Pressure Plunger Pump, 1/2 in, 6 hp, Solid

  • Mfr # RCA35G25N-PKG

  • Zoro # G410474481

product price:  $339.99
/ea
Free Shipping & Returns

Key Features

Lubrication
Oil Bath
Shaft Type
Solid
Required Gasoline Engine Horsepower (Maximum)
9 2/5 hp
Motor Speed (Maximum)
1,750 RPM
Shaft Outer Diameter
24 mm
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
RCA35G25N-PKG
Zoro #
G410474481
UPC #
192216232648
Country of Origin
Italy

Dimensions

Shaft Outer Diameter
24 mm
Intake Connection Size
1/2 in
Discharge Connection Size
3/8 in
Discharge Diameter
3/8 in
Inlet Diameter
1/2 in

Details

Item
Pressure Plunger Pump
Lubrication
Oil Bath
Shaft Type
Solid
Required Gasoline Engine Horsepower (Maximum)
9 2/5 hp
Motor Speed (Maximum)
1,750 RPM
Required Electric Motor Horsepower (Maximum)
6 hp
Power Source
Hydraulic Motor
Operating Pressure (Maximum)
2,500 psi
Discharge Connection Type
NPT
Drive Type
Belt-Drive
Flange Type
Horizontal Gas Engine
Piston Design
Triplex
Flow Rate (Maximum)
3.5 gpm
Pump Head Material
Forged Brass
Number of Pistons
3
Plunger Material
Ceramic
Intake Connection Type
FNPT
Discharge Pressure (Maximum)
2,500 psi
Pumping Element Layout
Inline
Manifold Material
Forged Brass
Compatible Drive Method
Belt Drive, Flex Coupling, Hydraulic Drive
Connecting Rod Material
Zinc-Aluminum
Drive Shaft Connection Type
Keyed
Shaft Seal Material
Buna-N
Media Temperature - Maximum
140 Degrees F
Pump Drive Configuration
Hydraulic-Driven
Rated Speed
1,750 RPM
Pumping Application
Agriculture and Livestock Washdown, Car and Vehicle Washing, Commercial and Industrial Cleaning, Fogging and Misting, Hydro Blasting and Water Jetting, Manufacturing and Plant Maintenance, Marine and Shipyard Maintenance, Mining, Oil and Gas Services, Paint Removal and Surface Preparation, Pipe Cleaning and Sewer Jetting, Pressure Washing
Series
RC Series
Engine Shaft Orientation
Horizontal
Number of Plungers
3
Power Source - TS Only
Hydraulic Motor

Description

Pressure Plunger Pump, Discharge Connection Size 3/8 in, Discharge Connection Type NPT, Discharge Pressure (Maximum) 2,500 psi, Flow Rate (Maximum) 3.5 gpm, Intake Connection Size 1/2 in, Intake Connection Type FNPT, Motor Speed (Maximum) 1,750 RPM, Piston Design Triplex, Pump Head Material Forged Brass, Plunger Material Ceramic, Required Electric Motor Horsepower (Maximum) 6 hp, Required Gasoline Engine Horsepower (Maximum) 9 2/5 hp, Lubrication Oil Bath, Shaft Outer Diameter 24 mm
