General Purpose Motor, 115V AC/230V AC
Mfr # JML3606T
Zoro # G7046210
product price: $1,427.48
/ea
Free Shipping & Returns
Key Features
Motor Design
Capacitor-Start
HP
3
RPM Range
3,001-3,600
Nameplate RPM
3,450
Voltage
115V AC, 230V AC
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
JML3606T
Zoro #
G7046210
UPC #
781568145500
Country of Origin
United States
Dimensions
Shaft Length
3 5/8 in
Length Less Shaft
14 7/16 in
Overall Length
18 1/16 in
Shaft Dia.
7/8 in
Description
Close-Coupled Pump Motor, Single Phase, Motor Design Capacitor-Start, 3 HP, Nameplate RPM 3,450, No. of Speeds 1, Voltage 115V AC, 230V AC, Full Load Amps 14.5/15/29 A, 182JM Frame, Usable @ 208V Yes, Hz 60 Hz, Motor Service Factor 1.15, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class F, NEMA Design L, Motor Enclosure Design Totally Enclosed Fan-Cooled, Motor Shaft Rotation CCW, Motor Mounting Type Rigid Base, Motor Mounting Position Horizontal
