Shop CENTURY

Motor, 1/3 HP, OEM Replacement Brand: Copeland Replacement For: 6127

  • Mfr # OCP0108

  • Zoro # G2374994

product price:
$
254.99
/ea
Free Shipping & Returns

Key Features

Frame
48Y
HP
1/3 HP
Motor Application
OEM Replacement
Motor Design
Permanent Split Capacitor
Motor Enclosure Design
Totally Enclosed
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
OCP0108
Zoro #
G2374994
UPC #
-
Country of Origin
Mexico
Frame
48Y
HP
1/3 HP
Item
Motor
Motor Application
OEM Replacement
Motor Design
Permanent Split Capacitor
Motor Enclosure Design
Totally Enclosed
Motor Mounting Type
Resilient Base
Motor Shaft Rotation
Clockwise Lead End
Motor Sub Application
Condenser Fan Motor
Motor Thermal Protection
Automatic
Nameplate RPM
1625 rpm
No. of Speeds
1
Number of Shafts
1
OEM Replacement Brand
Copeland
Phase
1
RPM Range
1601-1700
Voltage
208-230V
Motor Bearings
Ball
Replacement For
6127
Ins. Class
A
Max. Ambient Temp.
50 Degrees C
Duty
Air Over
Full Load Amps
2.6A
Capacitor Required
Included
Standards
UL Recognized, CSA Certified
Motor Shaft Design
Flat
Hz
60 Hz
Motor Service Factor
1.00
Application
Condenser Fan
Voltage Compatibility
115/208-230V AC, 208-230V AC, 208-240V AC
Motor Mounting Position
Horizontal
Weight
15 lb
Motor Frame Material
Steel
Usable @ 208V
Usable at 208V
Usable @ 200V
Not Usable at 200V
Conduit Box Position
F3
Rotation
CWLE
Mounting
Cradle Base
Number of Speeds
1
Compatible Brand
Copeland
Ambient Temperature - Maximum
50 Degrees C
Nameplate Service Factor @ 60 Hz
1
Frame Material
Steel
Bearing Type
Ball
Mounting Position
Horizontal
Sub Application
Condenser Fan
Product Type
Condenser Fan Motor
Full Load Current @ 60 Hz
2.6 A
Shaft Design
Flat
Insulation Class
A
Motor Enclosure Type
Totally Enclosed Air-Over

Description

Condenser Fan Motor, Single Phase, Motor Design Permanent Split Capacitor, 1/3 hp HP, Nameplate RPM 1,625 RPM, No. of Speeds 1, Voltage 208-230V AC, Full Load Amps 2.6 A, 48Y Frame, OEM Replacement Brand Copeland, Replacement For 6127, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, 60/50 Hz, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class A, Max. Ambient Temp. 50 Degrees C, Motor Shaft Rotation CCWSE, Motor Enclosure Design Totally Enclosed Air-Over
