Century Pool Pump Motor, Capacitor-Start/Run, 1/10, 3/4 HP, 56J Frame, 3,450/1,725 Nameplate RPM STS1072RV1

This item is Discontinued.

Century

Pool Pump Motor, Capacitor-Start/Run, 1/10, 3/4 HP, 56J Frame, 3,450/1,725 Nameplate RPM (Discontinued)

Mfr # STS1072RV1
Zoro # G8651542
Country of Origin Mexico
Category Pool Pump Motors
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
STS1072RV1
Zoro #
G8651542
UPC #
-
Country of Origin
Mexico

Dimensions

Shaft Length
2 5/8 in
Shaft Dia.
5/8 in
Length Less Shaft
12 1/8 in
Overall Length
14 11/16 in
Shaft Diameter
5/8 in
Body Diameter
6.5 in
Frame Size
56J

Details

Item
Pool and Spa Pump Motor
Motor Design
Capacitor-Start/Run
Motor Enclosure Design
Open Dripproof
HP
1/10, 3/4
Motor Service Factor
1.5
RPM Range
3,001-3,600
Nameplate RPM
3,450/1,725
Frame
56J
Motor Shaft Rotation
CCWSE
Phase
Single
Voltage
230V AC
Full Load Amps
5.4/2.2
Motor Mounting Type
Face
Hz
60 Hz
Shaft Material
Stainless Steel
Ambient Temperature
50 Degrees C
Standards
California Energy Commission Appliance Regulations 2008, CSA, UL
Motor Sub Application
Pool and Spa Pump
Max. Ambient Temp.
50 Degrees C
Finish
Unfinished
Shaft
Threaded
Motor Bearings
Ball
Motor Application
Pump
Motor Thermal Protection
Auto
Voltage Compatibility
115/200-230V AC, 115/208-230V AC, 115/230V AC, 120/240V AC, 200-230/440V AC, 200-230/460V AC, 208-220/440V AC, 208-230/277V AC, 208-230/460V AC, 230V AC, 240V AC, 277/230V AC
Motor Flange Material
Aluminum
Ins. Class
B
Motor Frame Material
Steel
Usable @ 200V
Not Usable at 200V
Motor Shaft Design
Threaded
No. of Speeds
2
Motor Mounting Position
Horizontal
Usable @ 208V
Not Usable at 208V
Weight
28 lb
Duty Cycle
Continuous
Conduit Box Position
F3
Sub Application
Pool and Spa Pump
Mounting Position
Horizontal
Motor Enclosure Type
Open Drip Proof
Full Load Current @ 60 Hz
5.4/2.2 A
Application
Pump
Bearing Type
Ball
Product Type
Pump Motor
Frame Material
Steel
Insulation Class
B
Shaft Design
Threaded
Nameplate Service Factor @ 60 Hz
1.5
Frame Finish
Unfinished
Number of Speeds
2
Number of Wires
9
Frequency
60 Hz
Ambient Temperature - Maximum
50 Degrees C

Description

Pool Pump Motor, Conduit Box Position F3, Duty Cycle Continuous, Finish Unfinished, Frame 56J, Hz 60 Hz, Full Load Amps 5.4/2.2, HP 1/10, 3/4, Ins. Class B, Length Less Shaft 12 1/8 in, Max. Ambient Temp. 50 Degrees C, Motor Application Pump, Motor Bearings Ball, Motor Design Capacitor-Start/Run, Motor Efficiency Group Energy Efficient, Motor Enclosure Design Open Dripproof, Motor Frame Material Steel

Restrictions

This item has been restricted from sale in the following states: NY
